Ariel FH 650 Huntmaster
1957Allround

Ariel FH 650 Huntmaster

Key specifications

Engine
646 cc
Power
35 HP
Fuel type
petrol
Fuel capacity
4.0 L
Transmission
4-speed
Seat height
31 mm
Front brakes
Expanding brake (drum brake)
Rear brakes
Expanding brake (drum brake)

Overview

Introducing the 1957 Ariel FH 650 Huntmaster, a quintessential British motorcycle that embodies the spirit of the post-war era. As a member of Ariel's illustrious family of motorcycles, the Huntmaster was designed for versatility and performance, making it an allrounder that appealed to a broad spectrum of riders—from the daily commuter to the weekend adventurer. With its striking black and yellow color scheme, the Huntmaster stands out as a classic statement of style and engineering prowess that continues to attract vintage motorcycle enthusiasts and collectors alike. At the heart of the Huntmaster is a robust 646 cc twin-cylinder, four-stroke engine, delivering a spirited 35 horsepower at 5600 RPM. This well-engineered powerplant, coupled with a 4-speed gearbox, allows riders to experience exhilarating acceleration and a top speed of nearly 93 mph. The engine's design features a compression ratio of 6.5:1, ensuring a smooth and responsive ride. The Amal carburettor facilitates efficient fuel delivery, while the air-cooled system keeps things running optimally even on the hottest days. Riders can expect a delightful blend of power and control, with the bike’s weight of 410 pounds providing a stable platform for spirited riding. The 1957 Ariel FH 650 Huntmaster also boasts several features that enhance its appeal. Its duplex down tube frame with a swingarm design not only contributes to the motorcycle's aesthetic appeal but also improves handling dynamics. The front telescopic fork and dual coil spring rear suspension work together to provide a comfortable ride, effectively absorbing bumps on the road. The drum brakes, while not as advanced as modern disc systems, offer reliable stopping power that complements the bike's classic character. With a fuel capacity of 15.14 liters, riders can enjoy longer journeys without frequent stops, making it practical for both commuting and leisure rides. **

Pros

  • Classic Styling: The distinctive black and yellow color scheme and vintage design elements make the Huntmaster a true head-turner.
  • Solid Performance: With a powerful engine and responsive handling, this motorcycle delivers an exciting riding experience.
  • Versatile Riding Capabilities: Perfectly positioned as an allrounder, it’s suitable for both casual rides and longer journeys.

Cons

  • Weight Consideration: At 410 pounds, some riders may find the Huntmaster a bit hefty, especially at low speeds.
  • Drum Brakes: While reliable, the drum brakes may not provide the same stopping power and feel as modern disc brakes.
  • Kick Start Only: The absence of an electric starter means riders must rely on the traditional kick start, which can be challenging for some, especially in tricky situations.

Technical details

Source specification data

Make
Ariel
Model
FH 650 Huntmaster
Category
Allround
Starter
Kick
Electrical
6V system
Color Options
Black/Yellow
Power
35.00 HP (25.5 kW)) @ 5600 RPM
Gearbox
4-speed
Ignition
Magneto
Top Speed
148.9 km/h (92.5 mph)
Engine Type
BSA A10 engine
Fuel System
Carburettor. Amal
Bore X Stroke
70.0 x 84.0 mm (2.8 x 3.3 inches)
Compression
6.5:1
Displacement
646.00 ccm (39.42 cubic inches)
Cooling System
Air
Engine Details
Twin, four-stroke
Exhaust System
Twin pipe
Lubrication System
Dry sump, two pumps
Transmission Type Final Drive
Chain
Seat Height
787 mm (31.0 inches) If adjustable, lowest setting.
Oil Capacity
2.30 litres (0.15 quarts)
Fuel Capacity
15.14 litres (4.00 gallons)
Overall Width
640 mm (25.2 inches)
Overall Length
2,184 mm (86.0 inches)
Ground Clearance
140 mm (5.5 inches)
Reserve Fuel Capacity
255.49 litres (67.50 gallons)
Weight Incl Oil Gas Etc
186.0 kg (410.0 pounds)
Wheels
Steel, wire spokes
Rear Tyre
3.50-19
Frame Type
Duplex down tubes, swingarm
Front Tyre
3.25-19
Rear Brakes
Expanding brake (drum brake)
Front Brakes
Expanding brake (drum brake)
Rear Suspension
Dual coil springs
Front Suspension
Telescopic fork, hydraulic

Available colors

Black/Yellow
