Ariel VHA 500
1953Allround

Ariel VHA 500

Key specifications

Engine
497 cc
Power
24 HP
Fuel type
petrol
Fuel capacity
3.5 L
Transmission
4-speed
Front brakes
Expanding brake (drum brake)
Rear brakes
Expanding brake (drum brake)

Overview

Introducing the 1953 Ariel VHA 500: A Timeless Allrounder The 1953 Ariel VHA 500 stands as a testament to the golden age of British motorcycling, representing a harmonious blend of classic design and robust engineering. Positioned as an allround motorcycle, it appeals to enthusiasts seeking a reliable companion for both leisurely rides and spirited commutes. With its elegant lines, available in striking colors like Wedgwood Blue and Deep Claret Red, the VHA 500 captures the timeless charm of mid-20th century motorcycles while delivering a ride that remains relevant to this day. Unleashing the Power of the Single Cylinder At the heart of the Ariel VHA 500 lies a spirited single-cylinder, four-stroke engine with a displacement of 497cc, producing a respectable 24 horsepower at 6000 RPM. This power, coupled with a compression ratio of 6.0:1, provides a thrilling yet manageable ride, perfect for both novice and experienced riders. The Amal monoblock carburettor ensures smooth fuel delivery, while the air-cooling system keeps the engine running efficiently even in demanding conditions. The 4-speed gearbox allows for seamless gear changes, enabling riders to tap into the bike’s full potential. With a weight of 168 kg (370.4 pounds), the VHA 500 delivers a well-balanced experience, making it a joy to navigate through twists and turns. Classic Features and Innovations The Ariel VHA 500 is equipped with key features that enhance both its performance and rider comfort. The semi-double cradle frame provides excellent stability, while the rigid rear suspension and grider forks at the front work in concert to deliver a smooth ride over various terrains. Drum brakes on both the front (178 mm) and rear (178 mm) ensure reliable stopping power, a crucial aspect for maintaining safety on the road. The kick starter adds a touch of nostalgia, allowing riders to connect with the bike in a way that modern electric starters often overlook. With a fuel capacity of 13.25 liters (3.50 gallons), the VHA 500 promises ample range for those long country rides, making it a versatile choice for various riding styles. **

Pros

    Cons

    • Classic Aesthetic: Timeless design and color options appeal to vintage motorcycle enthusiasts.
    • Reliable Performance: A well-balanced engine and lightweight frame make it a joy to ride.
    • Comfortable Ride: The combination of a semi-double cradle frame and effective suspension contributes to a smooth experience.
    • Limited Power: While 24 HP is sufficient for casual riding, it may be underwhelming for those seeking high-performance thrills.
    • Drum Brakes: Though reliable, drum brakes may not offer the stopping power found in modern disc brake systems.
    • Rigid Rear Suspension: While it enhances the classic look, it may not provide the comfort of more modern suspension designs on longer rides.

    Technical details

    Source specification data

    Make
    Ariel
    Model
    VHA 500
    Category
    Allround
    Starter
    Kick
    Color Options
    Wedgwood Blue, Deep Claret Red
    Power
    24.00 HP (17.5 kW)) @ 6000 RPM
    Clutch
    Dry
    Gearbox
    4-speed
    Driveline
    Burman
    Engine Type
    All-alloy engine
    Fuel System
    Carburettor. Amal monoblock
    Bore X Stroke
    81.0 x 95.0 mm (3.2 x 3.7 inches)
    Compression
    6.0:1
    Displacement
    497.00 ccm (30.33 cubic inches)
    Cooling System
    Air
    Engine Details
    Single cylinder, four-stroke
    Lubrication System
    Dry sump with dual plunger pumps
    Transmission Type Final Drive
    Chain
    Oil Capacity
    3.40 litres (0.22 quarts)
    Fuel Capacity
    13.25 litres (3.50 gallons)
    Overall Width
    640 mm (25.2 inches)
    Overall Length
    2,180 mm (85.8 inches)
    Ground Clearance
    140 mm (5.5 inches)
    Weight Incl Oil Gas Etc
    168.0 kg (370.4 pounds)
    Seat
    Single or dual seat
    Wheels
    Dunlop tyres.
    Rear Tyre
    3.25-19
    Frame Type
    Semi double cradle
    Front Tyre
    3.00-20
    Rear Brakes
    Expanding brake (drum brake)
    Front Brakes
    Expanding brake (drum brake)
    Rear Suspension
    Rigid
    Front Suspension
    Grider forks
    Rear Brakes Diameter
    178 mm (7.0 inches)
    Front Brakes Diameter
    178 mm (7.0 inches)

    Available colors

    Wedgwood BlueDeep Claret Red
