Back to Bike FinderYears: 2013
2013Sportbike
Bimota DB11 VLX
Key specifications
Engine
1198 cc
Power
188 HP
Torque
142 Nm
Weight
179 kg
Fuel type
petrol
Fuel capacity
4.8 L
Transmission
6-speed
Seat height
32 mm
Front brakes
Double disc. Brembo radial, 4 pistons calipers
Rear brakes
Single disc. Bremo 2-pistons
Technical details
Source specification data
- Make
- Bimota
- Model
- DB11 VLX
- Category
- Sport
- Starter
- Electric
- Comments
- Sprintex dual-screw supercharger modified by Bimota
- Color Options
- White/red
- Power
- 188.00 HP (137.2 kW)) @ 9500 RPM
- Clutch
- Wet, Multi-plate
- Torque
- 142.38 Nm (14.5 kgf-m or 105.0 ft.lbs) @ 8000 RPM
- Gearbox
- 6-speed
- Top Speed
- 260.0 km/h (161.6 mph)
- Engine Type
- Supercharged Ducati Testastretta engine
- Fuel System
- Injection
- Bore X Stroke
- 106.0 x 67.9 mm (4.2 x 2.7 inches)
- Compression
- 11.5:1
- Displacement
- 1198.00 ccm (73.10 cubic inches)
- Cooling System
- Liquid
- Engine Details
- V2, four-stroke
- Exhaust System
- Athena 2 in 1 in 1, Titanium silencer.
- Lubrication System
- Wet sump
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Dry Weight
- 178.7 kg (394.0 pounds)
- Seat Height
- 800 mm (31.5 inches) If adjustable, lowest setting.
- Oil Capacity
- 3.00 litres (0.20 quarts)
- Fuel Capacity
- 18.00 litres (4.76 gallons)
- Overall Width
- 730 mm (28.7 inches)
- Power Weight Ratio
- 1.0519 HP/kg
- Rake
- 25.0°
- Rear Tyre
- 190/55-ZR17
- Frame Type
- NiCrMo4 steel and aluminium plates
- Front Tyre
- 120/70-ZR17
- Rear Brakes
- Single disc. Bremo 2-pistons
- Front Brakes
- Double
- disc.
- Brembo
- radial, 4 pistons calipers
- Rear Suspension
- Extreme Tech
- .
- Preload
- -fully adjustable top and lower speed monoshock
- Front Suspension
- Marzocchi
- 43mm preload -fully adjustable and
- C
- treated upside-down forks
- Rear Brakes Diameter
- 230 mm (9.1 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
White/red
