CCM C-XR125-E
2009Off-road

CCM C-XR125-E

Key specifications

Engine
124 cc
Weight
118 kg
Fuel type
petrol
Fuel capacity
2.3 L
Seat height
36 mm
Front brakes
Single disc
Rear brakes
Single disc

Overview

Introducing the 2009 CCM C-XR125-E, a spirited enduro-offroad motorcycle crafted for both budding riders and seasoned adventurers alike. Known for its blend of lightweight agility and robust performance, the C-XR125-E embodies the essence of off-road exploration. Positioned in the competitive entry-level segment, this bike is designed for riders who crave the thrill of navigating rugged terrains without compromising on the fun factor. With its striking red finish and rugged build, the C-XR125-E not only turns heads but also invites you to push boundaries on trails and tracks. At the heart of the C-XR125-E lies a feisty 124cc single-cylinder, four-stroke engine, delivering a punchy performance that is both exhilarating and manageable. With a compression ratio of 9.0:1 and a bore and stroke of 56.5 x 49.5 mm, this engine is engineered for durability and efficiency. The electric start feature adds to the bike's user-friendly nature, allowing for quick getaways on the trail. With a final drive via chain and a lightweight frame tipping the scales at just 118 kg (260.1 lbs), riders will enjoy nimble handling and responsive acceleration, making it a perfect companion for technical climbs or spirited runs across open fields. The 21-inch front and 18-inch rear wheels further enhance maneuverability, ensuring the bike can tackle obstacles with confidence. Equipped with a tubular welded steel frame, the C-XR125-E boasts a conventional 40mm front suspension and a single adjustable rear shock, which can be fine-tuned to accommodate various riding styles and terrains. This versatility is complemented by the bike’s impressive ground clearance of 340 mm (13.4 inches), allowing riders to glide over rough patches and rocks without a hitch. Safety is prioritized with single disc brakes at both the front and rear, ensuring reliable stopping power when you need it most. Additionally, the 8.80-liter fuel tank provides ample range for extended adventures, making it an excellent choice for those long weekend rides. **

Pros

  • Lightweight and Nimble: Weighing just 118 kg, the C-XR125-E offers excellent handling and maneuverability, making it ideal for both beginners and experienced riders.
  • User-Friendly Features: The electric start, combined with its straightforward controls, allows for easy operation, especially for new riders.
  • Versatile Suspension: The adjustable rear suspension and ample ground clearance provide the flexibility needed to tackle a variety of terrains confidently.

Cons

  • Limited Power for Highway Use: While perfect for trails and off-road riding, the 124cc engine may struggle to keep up on faster highways.
  • Seat Height: With a seat height of 920 mm (36.2 inches), it may be a challenge for shorter riders to comfortably reach the ground.
  • Basic Instrumentation: The bike’s instrumentation is minimal, lacking advanced tech features that more modern bikes may offer.

Technical details

Source specification data

Make
CCM
Model
C-XR125-E
Category
Enduro-offroad
Starter
Electric
Comments
Wheels 21´, 18´
Color Options
Red
Ignition
C.D.I.
Bore X Stroke
56.5 x 49.5 mm (2.2 x 1.9 inches)
Compression
9.0:1
Displacement
124.00 ccm (7.57 cubic inches)
Engine Details
Single cylinder, four-stroke
Lubrication System
Wet sump
Transmission Type Final Drive
Chain
Dry Weight
118.0 kg (260.1 pounds)
Seat Height
920 mm (36.2 inches) If adjustable, lowest setting.
Fuel Capacity
8.80 litres (2.32 gallons)
Ground Clearance
340 mm (13.4 inches)
Frame Type
Tubular welded steel
Rear Brakes
Single disc
Front Brakes
Single disc
Rear Suspension
Single shock - adjustable preload
Front Suspension
Conventional 40mm

Available colors

Red
