Introducing the 2018 CCM Spitfire: A Naked Bike with Character The 2018 CCM Spitfire is a striking entry in the naked bike category, designed for riders who crave a blend of style, performance, and lightweight agility. Known for its unique aesthetic and hand-crafted quality, the Spitfire stands out in a crowded market filled with mass-produced machines. With its sleek lines and modern retro appeal, this motorcycle is not just a mode of transport but a statement of individuality. CCM (Clews Competition Machines) has cultivated a loyal following, and the Spitfire exemplifies the brand's commitment to craftsmanship and performance, making it a desirable choice for both seasoned riders and newcomers alike. Engine Performance and Riding Characteristics Underneath its captivating exterior lies a robust heart: a single-cylinder, four-stroke engine displacing 600cc. This powerplant generates an impressive 55 HP and 58 Nm of torque at 5,500 RPM, ensuring that the Spitfire delivers exhilarating acceleration and a thrilling ride. The 6-speed gearbox allows for seamless shifting, enhancing the overall riding experience, whether you're navigating city streets or cruising along winding country roads. With a compression ratio of 12.0:1 and a Mikuni D45 fuel injection system, the Spitfire provides not only spirited performance but also commendable fuel efficiency of 4.20 liters per 100 km, making it an economical choice for daily commuting and weekend adventures alike. Key Features and Technology The Spitfire's chassis is as impressive as its engine, boasting a high-strength steel frame that is hand TIG welded for maximum durability and a lightweight feel. Weighing in at just 135 kg (297.6 pounds), this bike is nimble and easy to handle, with a rake of 26 degrees and a trail of 118 mm ensuring responsive steering. The front and rear single disc brakes provide reliable stopping power, while the telescopic front fork and single rear shock suspension system contribute to a comfortable ride, absorbing bumps and uneven surfaces with ease. With an electric starter and a stylish color option of silver and gold, the Spitfire combines modern technology with classic aesthetics, appealing to a diverse range of motorcycle enthusiasts. **
Pros
Cons
- Unique Design: The distinctive styling sets the Spitfire apart in the naked bike segment, appealing to riders looking for something different.
- Lightweight and Agile: Weighing only 135 kg, the bike offers exceptional maneuverability, making it ideal for urban commuting and spirited rides.
- Impressive Fuel Efficiency: At 4.20 liters per 100 km, the Spitfire is economical, allowing for extended rides without frequent stops for fuel.
- Limited Power: While 55 HP is sufficient for many riders, those seeking high-performance thrills might find it lacking compared to larger displacement bikes.
- Single-Cylinder Vibration: The single-cylinder engine, while providing a unique riding experience, can result in more vibrations at higher speeds compared to multi-cylinder alternatives.
- Minimal Storage Options: The sleek design prioritizes aesthetics over practicality, potentially limiting storage for longer trips or commutes.
Technical details
Source specification data
- Make
- CCM
- Model
- Spitfire
- Category
- Naked bike
- Starter
- Electric
- Color Options
- Silver/gold
- Power
- 55.00 HP (40.1 kW))
- Clutch
- Multiple-disc, wet, Hydraulic control
- Torque
- 58.00 Nm (5.9 kgf-m or 42.8 ft.lbs) @ 5500 RPM
- Gearbox
- 6-speed
- Fuel System
- Injection. Mikuni D45
- Compression
- 12.0:1
- Displacement
- 600.00 ccm (36.61 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Fuel Consumption
- 4.20 litres/100 km (23.8 km/l or 56.00 mpg)
- Greenhouse Gases
- O2
- g/km. (
- O2
- -
- Carbon
- dioxide emission)
- Transmission Type Final Drive
- Chain
- Dry Weight
- 135.0 kg (297.6 pounds)
- Seat Height
- 830 mm (32.7 inches) If adjustable, lowest setting.
- Oil Capacity
- 1.80 litres (0.12 quarts)
- Fuel Capacity
- 14.00 litres (3.70 gallons)
- Overall Length
- 2,117 mm (83.3 inches)
- Ground Clearance
- 250 mm (9.8 inches)
- Power Weight Ratio
- 0.4074 HP/kg
- Rake
- 26.0°
- Trail
- 118 mm (4.6 inches)
- Wheels
- Maxxis DTR1 Tubed Flat Track Race tyre
- Rear Tyre
- 130/70-19
- Frame Type
- High strength steel, Hand Tig welded
- Front Tyre
- 130/70-19
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Single shock
- Front Suspension
- Telescopic fork
- Rear Brakes Diameter
- 240 mm (9.4 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
