Confederate Wraith
Key specifications
Overview
Introducing the 2010 Confederate Wraith, a motorcycle that embodies the spirit of American craftsmanship and cutting-edge engineering. Positioned in the naked bike category, the Wraith is not just a machine; it's a statement. With a limited production run of just 250 units, this bike is a rare gem in the motorcycle world, catering to enthusiasts who crave exclusivity and performance. Its striking design, characterized by an aggressive stance and minimalist aesthetics, is sure to turn heads wherever it roams. The Wraith is an emblem of Confederate's commitment to producing high-performance motorcycles that are as distinctive as they are powerful. At the heart of the Wraith lies a potent V2, four-stroke engine with a displacement of 1966.57 ccm (120.00 cubic inches). With a remarkable output of 125 HP and an impressive torque of 176.28 Nm, the Wraith delivers exhilarating acceleration and a thrilling ride that will satisfy even the most discerning riders. The meticulously engineered 6-speed gearbox allows for seamless shifts, enabling riders to harness the full potential of the engine with precision. The bike’s lightweight construction, tipping the scales at just 176.9 kg (390 lbs), combined with the power-to-weight ratio of 0.7066 HP/kg, ensures that the Wraith is agile and responsive, making it an absolute joy to navigate through twisty roads or urban landscapes. The Wraith is equipped with advanced features that enhance both performance and rider experience. Its carbon fiber monocoque frame, designed to withstand the rigors of high-speed riding, not only reduces weight but also enhances rigidity and stability. The fully adjustable Penske coil-over shocks, both front and rear, provide a custom-tailored ride quality, allowing riders to fine-tune their suspension settings for optimal comfort and handling. Braking is handled by high-performance Bremo components, featuring double discs at the front and a single disc at the rear, ensuring that stopping power is as formidable as its acceleration. Additional highlights include stunning carbon fiber wheels and an electric starter, reinforcing the Wraith's blend of style and technology. **
Pros
- Exclusivity: With only 250 units produced, owning a Wraith is a mark of distinction among motorcycle enthusiasts.
- Exceptional Performance: The powerful V2 engine provides thrilling acceleration and robust torque, making it a joy to ride.
- Advanced Engineering: The carbon fiber monocoque frame and adjustable suspension deliver a lightweight, rigid, and highly customizable ride.
Cons
- Limited Comfort: The naked bike design may sacrifice some rider comfort for aesthetics, particularly on longer rides.
- Niche Appeal: The unique styling and exclusivity may not appeal to all riders, potentially limiting its market.
- Price Point: As a limited-edition motorcycle, the Wraith comes with a premium price tag, which may deter budget-conscious buyers.
Technical details
Source specification data
- Make
- Confederate
- Model
- Wraith
- Category
- Naked bike
- Starter
- Electric
- Comments
- Carbon
- fiber wheels.
- Limited
- production of 250 bikes.
- Color Options
- Black/grey
- Power
- 125.00 HP (91.2 kW))
- Torque
- 176.28 Nm (18.0 kgf-m or 130.0 ft.lbs)
- Gearbox
- 6-speed
- Bore X Stroke
- 104.8 x 114.3 mm (4.1 x 4.5 inches)
- Displacement
- 1966.57 ccm (120.00 cubic inches)
- Engine Details
- V2, four-stroke
- Transmission Type Final Drive
- Belt
- Dry Weight
- 176.9 kg (390.0 pounds)
- Seat Height
- 775 mm (30.5 inches) If adjustable, lowest setting.
- Power Weight Ratio
- 0.7066 HP/kg
- Rake
- 27.0°
- Rear Tyre
- 280/55-17
- Frame Type
- Confederate
- design triple load path carbon fiber monocoque.
- Aircraft
- grade
- C
- billet bulkhead, fuselage.
- Oil
- in frame.
- Front Tyre
- 120/60-17
- Rear Brakes
- Single disc. Bremo, 2-piston
- Front Brakes
- Double disc. Bremo, 4-piston
- Rear Suspension
- Penske coil over shock with cooling reservoir; multi adjustable
- Front Suspension
- Penske coil over shock, fully adjustable
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
