Ducati Monster 796
2010Naked

Ducati Monster 796

Key specifications

Engine
803 cc
Power
86 HP
Torque
58 Nm
Weight
167 kg
Fuel type
petrol
Fuel capacity
4.0 L
Transmission
6-speed
Seat height
32 mm
Front brakes
Double disc
Rear brakes
Single disc

Overview

Introducing the 2010 Ducati Monster 796, a quintessential representation of the naked bike genre that seamlessly marries performance with striking Italian design. Positioned as an entry point into the Monster family, the 796 boasts the iconic trellis frame and muscular aesthetics that have defined Ducati's heritage. With its agile handling and user-friendly ergonomics, the Monster 796 appeals to both seasoned riders looking for a spirited ride and newcomers eager to experience the thrill of a true Ducati. Its sleek silhouette and aggressive stance ensure it's not just a mode of transport but a statement on two wheels. At the heart of the Monster 796 is its robust 803cc V2, four-stroke engine, delivering an exhilarating 85.83 horsepower at 8250 RPM. This powerplant is characterized by a harmonious blend of torque and responsiveness, with 58 Nm of torque available at a low 6250 RPM, making it a joy to ride in urban environments or on twisty back roads. The 6-speed gearbox, paired with a wet multiplate clutch, offers smooth transitions, while the air-cooled design keeps the engine performing optimally even in varying conditions. Riders will appreciate the bike's nimble weight of 167 kg, which, combined with a power-to-weight ratio of 0.5140 HP/kg, allows for quick acceleration and confident handling, making every ride an exciting adventure. The Monster 796 is not just about raw power; it’s also equipped with a host of features that enhance the overall riding experience. The Showa 43mm upside-down front forks and a Sachs adjustable monoshock at the rear provide superb stability and comfort, with a front travel of 120 mm and rear travel of 148 mm. Stopping power is delivered through a dual front disc setup, complemented by a single rear disc, ensuring that the bike can handle spirited riding with confidence. Additionally, the machine offers optional ABS for those who prioritize safety. Available in eye-catching colors like red, white, and black, the Monster 796 is as much about style as it is about substance, making it a versatile choice for riders looking to express their individuality. **

Pros

  • Powerful Engine Performance: The V2 engine delivers an exhilarating ride with impressive torque and horsepower, perfect for both city commuting and spirited weekend rides.
  • Lightweight and Agile: At just 167 kg, the Monster 796 offers excellent maneuverability, making it easy to handle in tight spaces and corners.
  • Stylish Design: The iconic Ducati styling, highlighted by the trellis frame and aggressive aesthetics, ensures that the Monster 796 stands out in any crowd.

Cons

  • Seat Height: With a seat height of 800 mm, it may pose a challenge for shorter riders, limiting accessibility for some.
  • Limited Wind Protection: As a naked bike, the Monster 796 lacks fairings, which may lead to increased wind resistance at higher speeds.
  • Fuel Capacity: The 15-litre fuel tank may require more frequent stops for fuel during long rides, which could be inconvenient for touring enthusiasts.

Technical details

Source specification data

Make
Ducati
Model
Monster 796
Category
Naked bike
Starter
Electric
Comments
Optional ABS.
Color Options
Red, white, black
Power
85.83 HP (62.6 kW)) @ 8250 RPM
Clutch
APTC wet multiplate with hydraulic control
Torque
58.00 Nm (5.9 kgf-m or 42.8 ft.lbs) @ 6250 RPM
Gearbox
6-speed
Fuel System
Injection
.
Siemens
electronic fuel injection, 45mm throttle body
Bore X Stroke
88.0 x 66.0 mm (3.5 x 2.6 inches)
Compression
11.0:1
Displacement
803.00 ccm (49.00 cubic inches)
Cooling System
Air
Engine Details
V2, four-stroke
Exhaust System
Lightweight 2-1-2 system with catalytic converter with twin lambda probes
Transmission Type Final Drive
Chain
Dry Weight
167.0 kg (368.2 pounds)
Seat Height
800 mm (31.5 inches) If adjustable, lowest setting.
Fuel Capacity
15.00 litres (3.96 gallons)
Power Weight Ratio
0.5140 HP/kg
Rake
24.0°
Rear Tyre
180/55-ZR17
Frame Type
Tubular steel Trellis frame
Front Tyre
120/70-ZR17
Rear Brakes
Single disc
Front Brakes
Double disc
Rear Suspension
Progressive
linkage with preload and rebound
Sachs
adjustable monoshock
Front Suspension
Showa 43mm upside-down forks
Rear Wheel Travel
148 mm (5.8 inches)
Front Wheel Travel
120 mm (4.7 inches)
Rear Brakes Diameter
245 mm (9.6 inches)
Front Brakes Diameter
320 mm (12.6 inches)

Available colors

Redwhiteblack
