Honda CB 1100
2014Classic

Honda CB 1100

Key specifications

Engine
1140 cc
Power
89 HP
Torque
93 Nm
Fuel type
petrol
Fuel capacity
3.9 L
Transmission
6-speed
Seat height
31 mm
Front brakes
Double disc. Floating discs. Four-piston calipers.
Rear brakes
Single disc. Single-piston.

Overview

Introducing the 2014 Honda CB 1100, a stunning homage to the classic motorcycles of yesteryears, blending timeless styling with modern engineering. Positioned firmly in the classic category, this bike is designed for those who appreciate the essence of motorcycling—a nod to the past while embracing the present. With its retro aesthetic, characterized by a sleek, minimalist design and a chrome-laden finish, the CB 1100 stands out as a stylish choice for riders seeking both nostalgia and performance in their everyday rides. At the heart of the CB 1100 lies a robust 1140cc in-line four-engine, delivering an impressive 88.51 horsepower at 7500 RPM and a torque of 93 Nm at 5000 RPM. This powertrain, paired with a smooth 6-speed gearbox, offers a delightful riding experience, whether cruising through city streets or taking on winding backroads. The liquid-cooled engine operates with a compression ratio of 9.5:1, ensuring consistent performance and efficiency. With a fuel consumption of approximately 5.41 liters per 100 km, riders can enjoy long journeys without frequent stops for fuel. The CB 1100 provides a balanced and confident ride, thanks to its carefully engineered frame geometry, featuring a rake of 27 degrees and a trail of 114 mm, which contributes to its stability and agility. The 2014 CB 1100 is not just about looks and performance; it also boasts an array of features designed to enhance the rider’s experience. Equipped with a sophisticated PGM-FI electronic fuel injection system, the bike ensures quick throttle response and optimal fuel efficiency. The double disc front brakes, paired with four-piston calipers, provide exceptional stopping power, while the adjustable 41mm front fork and dual rear shocks allow riders to customize their suspension settings for comfort and control. With a seat height of 795 mm, the bike caters to a wide range of riders, making it accessible for both new and seasoned enthusiasts. **

Pros

  • Classic Aesthetic: The retro design pays homage to Honda's rich heritage while still delivering modern performance.
  • Smooth Performance: The powerful engine combined with a 6-speed gearbox offers a thrilling yet comfortable ride.
  • Versatile Suspension: Adjustable front and rear suspension allows for a tailored riding experience, enhancing comfort on various terrains.

Cons

  • Weight: At 247 kg (544.5 lbs), the CB 1100 may feel heavy for some riders, especially during low-speed maneuvers.
  • Limited Technology: Lacks some modern technological features found in competing bikes, like advanced rider aids or TFT displays.
  • Fuel Capacity: With a 14.60-liter tank, longer rides may require more frequent fuel stops compared to some touring alternatives.

Technical details

Source specification data

Make
Honda
Model
CB 1100
Category
Classic
Starter
Electric
Comments
Model ID: CB1100
Electrical
YTZ14S WET 12V-11.2Ah battery.
Instruments
Fuel gauge, instant fuel consumption, remaining range, clock, new gear position indicator.
Factory Warranty
One
year.
Unlimited
milage.
Transferable
.
Power
88.51 HP (64.6 kW)) @ 7500 RPM
Clutch
Multi-plate wet clutch
Torque
93.00 Nm (9.5 kgf-m or 68.6 ft.lbs) @ 5000 RPM
Gearbox
6-speed
Ignition
Digital transistorized with electronic advance
Fuel System
Injection
.
M
-
I
electronic fuel injection
Bore X Stroke
73.5 x 67.2 mm (2.9 x 2.6 inches)
Compression
9.5:1
Displacement
1140.00 ccm (69.56 cubic inches)
Cooling System
Liquid
Engine Details
In-line four, four-stroke
Emission Details
Meets
current
A
standards.
California
version meets current
B
standards and may differ slightly due to emissions equipment.
Fuel Consumption
5.41 litres/100 km (18.5 km/l or 43.48 mpg)
Greenhouse Gases
O2
g/km. (
O2
-
Carbon
dioxide emission)
Transmission Type Final Drive
Chain
Seat Height
795 mm (31.3 inches) If adjustable, lowest setting.
Oil Capacity
4.90 litres (0.32 quarts)
Fuel Capacity
14.60 litres (3.86 gallons)
Ground Clearance
125 mm (4.9 inches)
Weight Incl Oil Gas Etc
247.0 kg (544.5 pounds)
Rake
27.0°
Trail
114 mm (4.5 inches)
Rear Tyre
140/70-18
Front Tyre
110/80-18
Rear Brakes
Single disc. Single-piston.
Front Brakes
Double
disc.
Floating
discs.
Four
-piston calipers.
Rear Suspension
Dual shocks with spring preload adjustability
Front Suspension
41mm fork with spring preload adjustability
Rear Brakes Diameter
256 mm (10.1 inches)
Front Brakes Diameter
296 mm (11.7 inches)
