Jawa-CZ 350
2012ATV

Jawa-CZ 350

Key specifications

Engine
366 cc
Weight
267 kg
Fuel type
petrol
Fuel capacity
4.3 L
Transmission
Automatic
Front brakes
Single disc. Hydraulic
Rear brakes
Single disc. Hydraulic

Overview

Introducing the 2012 Jawa-CZ 350, an exciting entry in the all-terrain vehicle (ATV) market that combines retro charm with modern engineering. This model pays homage to the legendary Jawa brand, renowned for its innovative designs and rugged reliability. The Jawa-CZ 350 is a versatile companion for both seasoned off-road enthusiasts and newcomers seeking a dependable ride that can tackle a variety of terrains. With its striking color options of red and black, this ATV not only performs well but also makes a statement on the trails. At the heart of the Jawa-CZ 350 lies a robust 366cc single-cylinder, four-stroke engine that delivers a thrilling ride. With a bore and stroke of 81.0 x 71.2 mm, the engine boasts a dynamic powerband that provides excellent torque and responsiveness, allowing riders to navigate challenges with confidence. The automatic gearbox and belt final drive ensure smooth transitions and effortless handling, making it easy for riders to focus on the adventure ahead. Coupled with an oil and air cooling system, the engine maintains optimal performance even under duress, making it a reliable choice for long excursions or tough off-road conditions. The chassis of the Jawa-CZ 350 is where form meets function. Built on a sturdy steel frame, this ATV is equipped with a fully independent double A-arm front suspension and a matching rear setup, offering an impressive front and rear travel of 178 mm (7.0 inches). This design not only enhances stability but also provides a comfortable ride over uneven surfaces. The dual hydraulic disc brakes ensure strong stopping power, giving riders peace of mind as they tackle steep descents or tricky corners. With a fuel capacity of 16.30 litres (4.31 gallons) and a ground clearance of 254 mm (10.0 inches), the Jawa-CZ 350 is ready for extended journeys into the wilderness. **

Pros

  • Powerful Engine Performance: The single-cylinder engine provides robust power and excellent torque, making it suitable for various terrains.
  • Comfortable Suspension: The fully independent suspension system allows for a smooth ride, effectively absorbing bumps and obstacles along the way.
  • Stylish Design: Available in eye-catching colors, the Jawa-CZ 350 stands out in both performance and aesthetics, appealing to a wide range of riders.

Cons

  • Weight: At 267 kg (588.6 pounds), this ATV may feel bulky for some riders, particularly in tight maneuvering situations.
  • Automatic Gearbox Limitations: While convenient, the automatic transmission may not provide the level of control that experienced riders desire in more rugged conditions.
  • Limited Technology Integration: Compared to newer models, the Jawa-CZ 350 may lack some advanced features and technologies that enhance rider experience and safety.

Technical details

Source specification data

Make
Arctic Cat
Model
350
Category
ATV
Starter
Electric
Electrical
12V 18 amps alternator.
Instruments
Digital
Color Options
Red, black
Carrying Capacity
Front Rack Capacity
75 lbs / 34 kg.
Rear Rack Capacity
150 lbs / 68.1 kg.
Towing Capacity
1,050 lbs / 476.3 kg
Gearbox
Automatic
Driveline
D
.
T
with
S
,
Hi
/
Lo Range
and
Reverse
.
Fuel System
Carburettor
Bore X Stroke
81.0 x 71.2 mm (3.2 x 2.8 inches)
Displacement
366.00 ccm (22.33 cubic inches)
Cooling System
Oil & air
Engine Details
Single cylinder, four-stroke
Valves Per Cylinder
4
Transmission Type Final Drive
Belt
Dry Weight
267.0 kg (588.6 pounds)
Fuel Capacity
16.30 litres (4.31 gallons)
Overall Width
1,130 mm (44.5 inches)
Overall Height
1,168 mm (46.0 inches)
Overall Length
2,116 mm (83.3 inches)
Ground Clearance
254 mm (10.0 inches)
Rear Tyre
24/10-12
Frame Type
Steel
Front Tyre
24/8-12
Rear Brakes
Single disc. Hydraulic
Front Brakes
Single disc. Hydraulic
Rear Suspension
Double A-Arm
Front Suspension
A
-
Arm
.
Fully Independent Suspension
.
Rear Wheel Travel
178 mm (7.0 inches)
Front Wheel Travel
178 mm (7.0 inches)

Available colors

Redblack
