Jincheng Monkey 50
2011Minibike

Jincheng Monkey 50

Key specifications

Engine
49 cc
Power
4 HP
Torque
3 Nm
Fuel type
petrol
Fuel capacity
1.5 L
Transmission
4-speed
Seat height
26 mm
Front brakes
Expanding brake (drum brake)
Rear brakes
Expanding brake (drum brake)

Overview

Introducing the 2011 Jincheng Monkey 50, a delightful minibike that perfectly encapsulates the joy of riding in a compact and playful package. With its roots tracing back to the iconic Honda Monkey bike, this modern rendition is designed for urban adventurers and those looking to dip their toes into the world of motorcycling. The Monkey 50 stands out in the minibike-cross category, appealing not only to first-time riders but also to seasoned enthusiasts who appreciate its nostalgic charm and agile performance. Primarily marketed in the Asian region, this little machine promises to deliver a unique blend of fun and practicality. At the heart of the Jincheng Monkey 50 lies a spirited 49cc single-cylinder, four-stroke engine that churns out a modest 3.62 horsepower at 8500 RPM. While the numbers might seem small, the bike’s lightweight frame, weighing in at just 68 kg (149.9 pounds), ensures that the power-to-weight ratio enables a lively ride. The 4-speed gearbox allows riders to shift smoothly through the gears, while the air-cooled engine maintains optimal operating temperatures for those spirited rides. The torque of 3.40 Nm at 5000 RPM provides enough oomph for quick accelerations, making city commuting and zipping around the neighborhood an absolute breeze. The Monkey 50 is not just about engine performance; it boasts an array of thoughtful features designed to enhance the riding experience. Its telescopic front fork and swingarm rear suspension provide a comfortable ride over various terrains, while the drum brakes—both front and rear—offer reliable stopping power. With a seat height of just 660 mm (26 inches), it’s accessible for riders of all sizes, making it an ideal choice for those who might be intimidated by larger motorcycles. The bike’s fuel capacity of 5.50 liters (1.45 gallons) ensures plenty of fun without frequent pit stops, and the vibrant red and white color options add a splash of style. **

Pros

  • Lightweight and Maneuverable: The compact size and weight make it easy to handle, perfect for new riders.
  • Nostalgic Design: The classic look evokes the charm of retro minibikes, appealing to enthusiasts of all ages.
  • Excellent Fuel Efficiency: With a modest engine size, the Monkey 50 offers impressive fuel economy, ideal for city riding.

Cons

  • Limited Power: The small engine may struggle on highways or steep inclines, limiting its versatility.
  • Basic Braking System: Drum brakes, while reliable, may not provide the same stopping power and responsiveness as modern disc brakes.
  • Market Availability: Primarily sold in the Asian market, it might be challenging for enthusiasts in other regions to find parts or support.

Technical details

Source specification data

Make
Honda
Model
Monkey 50
Category
Minibike-cross
Starter
Kick
Comments
Sold in the Asian market
Color Options
Red/white
Power
3.62 HP (2.6 kW)) @ 8500 RPM
Clutch
Wet, multiplate
Torque
3.40 Nm (0.3 kgf-m or 2.5 ft.lbs) @ 5000 RPM
Gearbox
4-speed
Ignition
Full transistor type battery ignition
Fuel System
Injection. PGM-FI
Bore X Stroke
39.0 x 41.1 mm (1.5 x 1.6 inches)
Compression
10.0:1
Displacement
49.00 ccm (2.99 cubic inches)
Cooling System
Air
Engine Details
Single cylinder, four-stroke
Transmission Type Final Drive
Chain
Seat Height
660 mm (26.0 inches) If adjustable, lowest setting.
Fuel Capacity
5.50 litres (1.45 gallons)
Overall Width
600 mm (23.6 inches)
Overall Height
850 mm (33.5 inches)
Overall Length
1,365 mm (53.7 inches)
Ground Clearance
145 mm (5.7 inches)
Weight Incl Oil Gas Etc
68.0 kg (149.9 pounds)
Rake
25.0°
Trail
42 mm (1.7 inches)
Rear Tyre
3.50-8
Front Tyre
3.50-8
Rear Brakes
Expanding brake (drum brake)
Front Brakes
Expanding brake (drum brake)
Rear Suspension
Swing Arm
Front Suspension
Telescopic fork

Available colors

Red/white
