KTM SX 125
Key specifications
Overview
Introducing the 2010 KTM SX 125, a formidable contender in the supermotard category that perfectly blends agility and power for both novice riders and seasoned enthusiasts alike. With its striking black color scheme and iconic KTM styling, this lightweight bike is designed for those who crave an exhilarating ride on both the streets and the track. Known for its sharp handling and robust performance, the SX 125 embodies the spirit of competition, making it a popular choice among young riders looking to hone their skills in the world of motocross and supermoto. At the heart of the SX 125 lies a spirited single-cylinder, two-stroke engine with a displacement of 122cc, delivering an impressive 21.45 horsepower. This powerhouse is coupled with a 6-speed gearbox, allowing the rider to tap into its full potential, reaching top speeds of 115 km/h (71.5 mph). The carburetor-fed Dell'Orto VHST 28 ensures responsive throttle control, while the liquid cooling system keeps the engine running efficiently even during extended rides. With a compression ratio of 12.5:1 and a lightweight design at just 115 kg, the SX 125 offers a thrilling ride that translates to superb acceleration and nimble cornering capabilities, making it a blast on twisty roads and racetracks alike. The SX 125 is equipped with a high-strength steel frame featuring a double trellis beam and a detachable seat frame, providing enhanced stability and durability. Its advanced suspension system includes a 40 mm upside-down hydraulic fork with 260 mm of wheel travel in the front and a hydraulic monoshock with a piggyback cylinder in the rear, offering exceptional handling and comfort over rough terrain. The braking system features single discs both front and rear, delivering reliable stopping power for confident rides. Additionally, the bike's compact dimensions and a seat height of 830 mm make it accessible to a wide range of riders, allowing for easy maneuverability and control. **
Pros
- Lightweight and Agile: Weighing just 115 kg, the SX 125 offers excellent maneuverability and quick handling, making it perfect for both city riding and track days.
- Powerful Engine Performance: The potent 122cc engine delivers impressive horsepower and acceleration, providing a thrilling riding experience.
- Advanced Suspension: The top-notch suspension components ensure superior handling and comfort, allowing riders to tackle various terrains with confidence.
Cons
- Limited Fuel Capacity: With a fuel tank that holds only 10 liters, long-distance rides may require frequent refueling stops.
- Kick Starter Only: The absence of an electric starter may deter some riders who prefer the convenience of a simple push-button ignition.
- Two-Stroke Maintenance: While two-stroke engines are known for their power, they typically require more regular maintenance and care compared to four-stroke counterparts.
Technical details
Source specification data
- Make
- Aprilia
- Model
- SX 125
- Category
- Super motard
- Starter
- Kick
- Color Options
- Black
- Power
- 21.45 HP (15.7 kW))
- Clutch
- Multi-plate wet clutch.
- Gearbox
- 6-speed
- Top Speed
- 115.0 km/h (71.5 mph)
- Fuel System
- Carburettor
- .
- Dell
- ’
- T
- 28 carburettor
- Bore X Stroke
- 54.0 x 54.5 mm (2.1 x 2.1 inches)
- Compression
- 12.5:1
- Displacement
- 122.00 ccm (7.44 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, two-stroke
- Lubrication System
- Separate mixing with variable displacement, volumetric pump.
- Transmission Type Final Drive
- Chain
- Dry Weight
- 115.0 kg (253.5 pounds)
- Seat Height
- 830 mm (32.7 inches) If adjustable, lowest setting.
- Fuel Capacity
- 10.00 litres (2.64 gallons)
- Overall Width
- 850 mm (33.5 inches)
- Overall Length
- 2,165 mm (85.2 inches)
- Power Weight Ratio
- 0.1865 HP/kg
- Rear Tyre
- 150/60-17
- Frame Type
- High
- strength steel frame with double trellis beam and double cradle.
- Detachable
- seat frame.
- Front Tyre
- 110/70-17
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Steel
- swingarm.
- Hydraulic
- monoshock with piggy back cylinder.
- Wheel
- travel 270 mm.
- Front Suspension
- 40 mm upside down hydraulic fork. Wheel travel 260 mm.
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 260 mm (10.2 inches)
