2005Minibike
Linhai 50 PY
Key specifications
Engine
49 cc
Power
3 HP
Torque
4 Nm
Weight
40 kg
Fuel type
petrol
Transmission
1-speed
Front brakes
Expanding brake (drum brake)
Rear brakes
Expanding brake (drum brake)
Technical details
Source specification data
- Make
- Linhai
- Model
- 50 PY
- Category
- Minibike-cross
- Starter
- Kick
- Comments
- Intended for children 5-7 years old.
- Power
- 2.54 HP (1.9 kW))
- Torque
- 3.70 Nm (0.4 kgf-m or 2.7 ft.lbs)
- Gearbox
- 1-speed
- Ignition
- C.D.I.
- Bore X Stroke
- 40.0 x 39.2 mm (1.6 x 1.5 inches)
- Displacement
- 49.00 ccm (2.99 cubic inches)
- Cooling System
- Air
- Engine Details
- Single cylinder, two-stroke
- Transmission Type Final Drive
- Shaft drive (cardan)
- Dry Weight
- 40.0 kg (88.2 pounds)
- Overall Width
- 575 mm (22.6 inches)
- Overall Height
- 715 mm (28.1 inches)
- Overall Length
- 1,245 mm (49.0 inches)
- Power Weight Ratio
- 0.0635 HP/kg
- Rear Brakes
- Expanding brake (drum brake)
- Front Brakes
- Expanding brake (drum brake)
- Rear Suspension
- UNit swing
- Front Suspension
- Telescopic fork
