2009Scooter
Malaguti Spidermax RS500
Key specifications
Engine
493 cc
Power
41 HP
Torque
40 Nm
Weight
204 kg
Fuel type
petrol
Fuel capacity
3.8 L
Transmission
Automatic
Seat height
30 mm
Front brakes
Single disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Malaguti
- Model
- Spidermax RS500
- Category
- Scooter
- Starter
- Electric
- Color Options
- Silver, titanium, dark blue
- Power
- 40.90 HP (29.9 kW))
- Clutch
- Centrifugal
- Torque
- 40.42 Nm (4.1 kgf-m or 29.8 ft.lbs) @ 7250 RPM
- Gearbox
- Automatic
- Fuel System
- Injection
- Bore X Stroke
- 94.0 x 71.0 mm (3.7 x 2.8 inches)
- Compression
- 10.5:1
- Displacement
- 493.00 ccm (30.08 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Exhaust System
- Euro
- 3.
- Catalytic
- converter by lambda sensor.
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Belt
- Dry Weight
- 204.0 kg (449.7 pounds)
- Seat Height
- 760 mm (29.9 inches) If adjustable, lowest setting.
- Fuel Capacity
- 14.50 litres (3.83 gallons)
- Overall Width
- 810 mm (31.9 inches)
- Overall Height
- 1,430 mm (56.3 inches)
- Overall Length
- 2,220 mm (87.4 inches)
- Power Weight Ratio
- 0.2005 HP/kg
- Rear Tyre
- 150/70-16
- Frame Type
- V-BOX aluminium monococque structure
- Front Tyre
- 120/80-16
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Swinging engine and double hdyraulic shock absorbers with adjustable spring preloading.
- Front Suspension
- 41 mm telescopic hydraulic fork
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 240 mm (9.4 inches)
Available colors
Silvertitaniumdark blue
