1962Sportbike
Matchless G3 CSR 350
Key specifications
Engine
347 cc
Weight
179 kg
Fuel type
petrol
Fuel capacity
5.1 L
Transmission
4-speed
Front brakes
Expanding brake (drum brake)
Rear brakes
Expanding brake (drum brake)
Technical details
Source specification data
- Make
- Matchless
- Model
- G3 CSR 350
- Category
- Sport
- Color Options
- Black-Red
- Clutch
- Wet multiplate
- Gearbox
- 4-speed
- Top Speed
- 129.0 km/h (80.2 mph)
- Fuel System
- Carburettor
- Bore X Stroke
- 74.0 x 81.0 mm (2.9 x 3.2 inches)
- Compression
- 6.5:1
- Displacement
- 347.00 ccm (21.17 cubic inches)
- Cooling System
- Air
- Engine Details
- Single cylinder, four-stroke
- Lubrication System
- Dry sump
- Transmission Type Final Drive
- Chain
- Dry Weight
- 179.0 kg (394.6 pounds)
- Fuel Capacity
- 19.30 litres (5.10 gallons)
- Seat
- Dual
- Wheels
- Spoked
- Rear Tyre
- 3.50-19
- Frame Type
- Single cradle
- Front Tyre
- 3.25-19
- Rear Brakes
- Expanding brake (drum brake)
- Front Brakes
- Expanding brake (drum brake)
- Rear Suspension
- Swinging arm- two shocks-coil springs
- Front Suspension
- Telescopic
Available colors
Black-Red
