Mondial SMX Motard
2020Super Moto

Mondial SMX Motard

Key specifications

Engine
124 cc
Power
15 HP
Torque
11 Nm
Weight
124 kg
Fuel type
petrol
Fuel capacity
1.7 L
Transmission
6-speed
Seat height
39 mm
Front brakes
Single disc. Floating discs. Two-piston calipers. ABS.
Rear brakes
Single disc. Floating disc. Single-piston caliper. ABS.

Overview

Introducing the 2020 FB Mondial SMX Motard, a spirited contender in the super motard category that beautifully marries Italian flair with nimble performance. As a product of the renowned FB Mondial brand, this motorcycle is designed for riders who seek the thrill of urban agility combined with the capability to tackle twisty backroads. With its eye-catching aesthetics available in dynamic color options of white/red and white/blue, the SMX Motard stands out not just in looks but also in its performance pedigree, making it a compelling choice for both new and seasoned motorcyclists alike. At the heart of the SMX Motard is its robust 124.20cc single-cylinder, four-stroke engine that delivers a respectable 14.75 HP at a thrilling 10,750 RPM. This peppy powerplant is designed for excitement, with a torque output of 11.00 Nm peaking at 8,000 RPM, ensuring brisk acceleration and responsive throttle control. The engine's liquid cooling and electronic fuel injection (EFI) work harmoniously to optimize performance and fuel efficiency, while the 6-speed gearbox allows for smooth gear transitions, enhancing the riding experience. With a lightweight frame tipping the scales at just 124 kg, the SMX Motard boasts an impressive power-to-weight ratio that promises exhilarating rides whether you’re weaving through city traffic or carving corners on country roads. The SMX Motard showcases advanced features that elevate its ride quality and safety. Its suspension system, featuring a 41 mm USD fork at the front and a single shock absorber at the rear, offers substantial travel—247 mm in the front and 270 mm in the rear—ensuring excellent handling on various surfaces. The braking system is equally commendable, equipped with ABS for both the front and rear single disc brakes, providing confidence-inspiring stopping power. The motorcycle's ground clearance of 250 mm is perfect for navigating urban obstacles, while the slightly adjustable seat height of 980 mm accommodates a wide range of rider sizes. This combination of technology and design makes the SMX Motard an ideal choice for those looking to blend style with functionality. **

Pros

  • Agile Performance: Lightweight and powerful, the SMX Motard excels in urban environments and twisty roads.
  • Stylish Design: The striking Italian aesthetics and color options make it a head-turner.
  • Advanced Safety Features: The inclusion of ABS enhances rider confidence, especially in varied conditions.

Cons

  • Limited Power for Highway Cruising: While great for city riding, the engine may feel underpowered for prolonged highway speeds.
  • Lower Fuel Capacity: At just 6.30 liters, the fuel tank may require more frequent stops on longer rides.
  • Seat Height: The seat height may pose a challenge for shorter riders, despite its adjustable feature.

Technical details

Source specification data

Make
FB Mondial
Model
SMX Motard
Category
Super motard
Starter
Electric
Comments
Italian brand.
Color Options
White/red, white/blue
Power
14.75 HP (10.8 kW)) @ 10750 RPM
Torque
11.00 Nm (1.1 kgf-m or 8.1 ft.lbs) @ 8000 RPM
Gearbox
6-speed
Fuel System
Injection. EFI
Bore X Stroke
58.0 x 47.0 mm (2.3 x 1.9 inches)
Compression
12.0:1
Displacement
124.20 ccm (7.58 cubic inches)
Cooling System
Liquid
Engine Details
Single cylinder, four-stroke
Lubrication System
Wet sump
Valves Per Cylinder
4
Transmission Type Final Drive
Chain
Dry Weight
124.0 kg (273.4 pounds)
Seat Height
980 mm (38.6 inches) If adjustable, lowest setting.
Fuel Capacity
6.30 litres (1.66 gallons)
Overall Width
825 mm (32.5 inches)
Overall Height
1,180 mm (46.5 inches)
Overall Length
2,080 mm (81.9 inches)
Ground Clearance
250 mm (9.8 inches)
Power Weight Ratio
0.1190 HP/kg
Rear Tyre
130/70-17
Front Tyre
100/80-17
Rear Brakes
Single
disc.
Floating
disc.
Single
-piston caliper.
S
.
Front Brakes
Single
disc.
Floating
discs.
Two
-piston calipers.
S
.
Rear Suspension
Single shock absorbers
Front Suspension
41 mm USD fork
Rear Wheel Travel
270 mm (10.6 inches)
Front Wheel Travel
247 mm (9.7 inches)
Rear Brakes Diameter
220 mm (8.7 inches)
Front Brakes Diameter
300 mm (11.8 inches)

Available colors

White/redwhite/blue
