Back to Bike FinderYears: 2007
2007Naked
Moto Guzzi 940 Custom
Key specifications
Engine
936 cc
Power
74 HP
Torque
78 Nm
Weight
245 kg
Fuel type
petrol
Fuel capacity
4.0 L
Transmission
5-speed
Seat height
31 mm
Front brakes
Double disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Moto Guzzi
- Model
- 940 Custom
- Category
- Naked bike
- Power
- 73.75 HP (53.8 kW)) @ 7200 RPM
- Torque
- 78.00 Nm (8.0 kgf-m or 57.5 ft.lbs) @ 6000 RPM
- Gearbox
- 5-speed
- Top Speed
- 190.0 km/h (118.1 mph)
- Bore X Stroke
- 95.0 x 66.0 mm (3.7 x 2.6 inches)
- Compression
- 10.0:1
- Displacement
- 936.00 ccm (57.11 cubic inches)
- Cooling System
- Air
- Engine Details
- Twin, four-stroke
- Exhaust System
- Katalysator
- Transmission Type Final Drive
- Shaft drive (cardan)
- Dry Weight
- 245.0 kg (540.1 pounds)
- Seat Height
- 780 mm (30.7 inches) If adjustable, lowest setting.
- Fuel Capacity
- 15.00 litres (3.96 gallons)
- Overall Width
- 875 mm (34.4 inches)
- Overall Length
- 2,205 mm (86.8 inches)
- Power Weight Ratio
- 0.3010 HP/kg
- Reserve Fuel Capacity
- 4.00 litres (1.06 gallons)
- Rear Tyre
- 180/55-17
- Frame Type
- Steel Frame
- Front Tyre
- 120/70-18
- Rear Brakes
- Single disc
- Front Brakes
- Double disc
- Rear Suspension
- Aluminium alloy single-piece swingarm. shock absorber adjustable in spring preload and rebound damping.
- Rear Wheel Travel
- 120 mm (4.7 inches)
- Front Wheel Travel
- 140 mm (5.5 inches)
- Rear Brakes Diameter
- 282 mm (11.1 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
