2012Classic
Moto Guzzi V7 Special
Key specifications
Engine
744 cc
Power
50 HP
Torque
60 Nm
Weight
179 kg
Fuel type
petrol
Fuel capacity
5.8 L
Transmission
5-speed
Seat height
32 mm
Front brakes
Single disc. Bremo stainless steel disc 4 opposed calipers of differing diameters
Rear brakes
Single disc. bremo
Technical details
Source specification data
- Make
- Moto Guzzi
- Model
- V7 Special
- Category
- Classic
- Starter
- Electric
- Color Options
- Red/white, yellow/black
- Power
- 50.00 HP (36.5 kW)) @ 6200 RPM
- Clutch
- Dry single plate with flexible couplings
- Torque
- 60.00 Nm (6.1 kgf-m or 44.3 ft.lbs) @ 2800 RPM
- Gearbox
- 5-speed
- Driveline
- Helicoidal
- gears, ratio 16/21=1:1.3125.
- Final
- drive:
- Shaft
- drive, ratio 4.825.
- Engine Type
- V 90 twin
- Fuel System
- Injection
- Bore X Stroke
- 80.0 x 74.0 mm (3.1 x 2.9 inches)
- Compression
- 9.6:1
- Displacement
- 744.00 ccm (45.40 cubic inches)
- Cooling System
- Air
- Engine Details
- V2, four-stroke
- Emission Details
- Three-way catalytic converter with double lambda probe
- Lubrication System
- By lobes with pressure pump
- Valves Per Cylinder
- 2
- Transmission Type Final Drive
- Shaft drive (cardan)
- Dry Weight
- 179.0 kg (394.6 pounds)
- Seat Height
- 805 mm (31.7 inches) If adjustable, lowest setting.
- Fuel Capacity
- 22.00 litres (5.81 gallons)
- Overall Width
- 805 mm (31.7 inches)
- Overall Height
- 1,115 mm (43.9 inches)
- Overall Length
- 2,185 mm (86.0 inches)
- Ground Clearance
- 182 mm (7.2 inches)
- Power Weight Ratio
- 0.2793 HP/kg
- Reserve Fuel Capacity
- 4.00 litres (1.06 gallons)
- Rake
- 27.5°
- Trail
- 109 mm (4.3 inches)
- Wheels
- Polished aluminium, spoked.
- Rear Tyre
- 130/80-17
- Frame Type
- ALS steel tubular dismountable twin cradle
- Front Tyre
- 100/90-18
- Rear Brakes
- Single disc. bremo
- Front Brakes
- Single
- disc.
- Bremo
- stainless steel disc 4 opposed calipers of differing diameters
- Rear Suspension
- Oscillating light alloy swingarm with 2 pre-load adjustable shock absorbers.
- Front Suspension
- Telescopic forks
- Rear Wheel Travel
- 118 mm (4.6 inches)
- Front Wheel Travel
- 130 mm (5.1 inches)
- Rear Brakes Diameter
- 260 mm (10.2 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
Red/whiteyellow/black
