Back to Bike FinderYears: 2019 · 2018
2018Off-road
Moto Morini Scrambler 1200
Key specifications
Engine
1187 cc
Power
117 HP
Torque
105 Nm
Weight
200 kg
Fuel type
petrol
Transmission
6-speed
Seat height
33 mm
Front brakes
Double disc. Brembo, 2-piston caliper
Rear brakes
Single disc. Brembo
Technical details
Source specification data
- Make
- Moto Morini
- Model
- Scrambler 1200
- Category
- Enduro-offroad
- Starter
- Electric
- Color Options
- Green
- Factory Warranty
- 3 years.
- Power
- 117.00 HP (85.4 kW)) @ 8500 RPM
- Clutch
- Multiple-plate clutch in oil bath with antiskipping system and radial master-cylinder
- Torque
- 105.00 Nm (10.7 kgf-m or 77.4 ft.lbs) @ 7000 RPM
- Gearbox
- 6-speed
- Engine Type
- 87 degree longitudinal V-twin.
- Fuel System
- Injection
- Bore X Stroke
- 107.0 x 66.0 mm (4.2 x 2.6 inches)
- Compression
- 12.2:1
- Displacement
- 1187.00 ccm (72.43 cubic inches)
- Cooling System
- Liquid
- Engine Details
- V2, four-stroke
- Emission Details
- Euro 3, 3-way catalyst, lambda probe
- Lubrication System
- Forced, with trochoidal pump
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Dry Weight
- 200.0 kg (440.9 pounds)
- Seat Height
- 830 mm (32.7 inches) If adjustable, lowest setting.
- Overall Width
- 850 mm (33.5 inches)
- Overall Height
- 1,160 mm (45.7 inches)
- Overall Length
- 2,140 mm (84.3 inches)
- Ground Clearance
- 180 mm (7.1 inches)
- Power Weight Ratio
- 0.5850 HP/kg
- Rake
- 26.5°
- Trail
- 127 mm (5.0 inches)
- Wheels
- Hot worked aluminium alloy
- Rear Tyre
- 150/70-R17
- Frame Type
- High-strength steel tube trellis
- Front Tyre
- 110/80-R19
- Rear Brakes
- Single disc. Brembo
- Front Brakes
- Double disc. Brembo, 2-piston caliper
- Rear Suspension
- Öhlins mono-shock-absorber on the side
- Front Suspension
- Upside down fork
- Rear Wheel Travel
- 165 mm (6.5 inches)
- Front Wheel Travel
- 155 mm (6.1 inches)
- Rear Brakes Diameter
- 255 mm (10.0 inches)
- Front Brakes Diameter
- 298 mm (11.7 inches)
Available colors
Green
