NCR M4
2007Super Moto

NCR M4

Key specifications

Engine
349 cc
Weight
133 kg
Fuel type
petrol
Fuel capacity
2.8 L
Transmission
6-speed
Seat height
34 mm
Front brakes
Single disc
Rear brakes
Single disc

Overview

Introducing the 2007 Beta M4, a motorcycle that perfectly encapsulates the spirit of the supermoto category. With its agile handling and robust design, the M4 is not just a machine; it’s an extension of your adventurous spirit. Beta, an esteemed name in the off-road segment, has successfully blended their expertise into a street-focused offering that excites both urban riders and trail enthusiasts alike. This bike is engineered for those who crave versatility without sacrificing performance, making it an attractive option in the competitive supermoto market. At the heart of the Beta M4 lies a powerful 349cc single-cylinder, four-stroke engine. This compact powerhouse is designed for maximum torque and responsiveness, delivering a thrilling ride whether you're slicing through city traffic or tackling twisty backroads. With a compression ratio of 9.5:1 and a carburetted fuel system featuring a Mikuni BST 33, the M4 ensures precise power delivery and smooth acceleration. Coupled with a six-speed gearbox, the M4 offers an exhilarating riding experience, allowing riders to exploit its full potential across varied terrains. The lightweight design, tipping the scales at just 133 kg (293.2 lbs), enhances maneuverability, making it easy to flick from side to side in tight corners. Beyond its impressive engine, the Beta M4 boasts a host of features that elevate its appeal. The steel double cradle frame provides optimal stability, while the hydraulic front fork with a 46 mm shaft and monoshock rear suspension with adjustable spring preload ensure a comfortable ride over uneven surfaces. With front and rear disc brakes sized at 310 mm and 220 mm respectively, riders can count on exceptional stopping power, instilling confidence during spirited rides. Additionally, the 10.5-litre fuel tank keeps you riding longer, and the adjustable seat height of 870 mm caters to a variety of rider sizes. Available in sleek silver or classic black, the M4 is as stylish as it is functional. **

Pros

  • Lightweight and Agile: At just 133 kg, the M4 offers exceptional maneuverability, allowing for easy handling in urban and off-road environments.
  • Versatile Performance: The powerful single-cylinder engine and six-speed transmission deliver a thrilling experience across a range of riding scenarios.
  • Adjustable Suspension: The rear monoshock with adjustable spring preload allows riders to fine-tune their setup for comfort and performance based on riding style and conditions.

Cons

  • Limited Fuel Capacity: With a 10.5-litre tank, longer rides may require more frequent refueling stops, which can be a downside for adventure-seeking riders.
  • Basic Electronics: The M4 features a straightforward electronic ignition system, which may lack some modern rider aids found on newer models.
  • Seat Height: While adjustable, the minimum seat height of 870 mm may not be ideal for shorter riders, potentially making it less accessible to all.

Technical details

Source specification data

Make
Beta
Model
M4
Category
Super motard
Color Options
Silver, black
Clutch
Wet multi-disc clutch
Gearbox
6-speed
Ignition
electronic
Fuel System
Carburettor. Mikuni BST 33
Bore X Stroke
79.0 x 71.2 mm (3.1 x 2.8 inches)
Compression
9.5:1
Displacement
349.00 ccm (21.30 cubic inches)
Cooling System
Air
Engine Details
Single cylinder, four-stroke
Lubrication System
Forced with pump
Valves Per Cylinder
4
Transmission Type Final Drive
Chain
Dry Weight
133.0 kg (293.2 pounds)
Seat Height
870 mm (34.3 inches) If adjustable, lowest setting.
Fuel Capacity
10.50 litres (2.77 gallons)
Overall Width
860 mm (33.9 inches)
Overall Height
1,220 mm (48.0 inches)
Overall Length
2,160 mm (85.0 inches)
Ground Clearance
305 mm (12.0 inches)
Reserve Fuel Capacity
3.00 litres (0.79 gallons)
Rear Tyre
4.25-17
Frame Type
steel double cradle frame
Front Tyre
3.5-17
Rear Brakes
Single disc
Front Brakes
Single disc
Rear Suspension
Monoshock with adjustable spring preload
Front Suspension
Hydraulic fork with ø46 mm shaft
Front Wheel Travel
46 mm (1.8 inches)
Rear Brakes Diameter
220 mm (8.7 inches)
Front Brakes Diameter
310 mm (12.2 inches)

Available colors

Silverblack
