Back to Bike FinderYears: 2016
2016Scooter
Over B3 50
Key specifications
Engine
49 cc
Power
4 HP
Weight
84 kg
Fuel type
petrol
Fuel capacity
1.8 L
Transmission
Automatic
Seat height
32 mm
Front brakes
Single disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Over
- Model
- B3 50
- Category
- Scooter
- Starter
- Electric & kick
- Comments
- Also called Overbikes B3 50.
- Color Options
- Red/white,
- Power
- 4.43 HP (3.2 kW)) @ 5000 RPM
- Gearbox
- Automatic
- Ignition
- C.D.I.
- Driveline
- CVT
- Fuel System
- Carburettor
- Bore X Stroke
- 40.0 x 39.2 mm (1.6 x 1.5 inches)
- Compression
- 12.5:1
- Displacement
- 49.00 ccm (2.99 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, two-stroke
- Transmission Type Final Drive
- Belt
- Dry Weight
- 84.0 kg (185.2 pounds)
- Seat Height
- 810 mm (31.9 inches) If adjustable, lowest setting.
- Fuel Capacity
- 6.80 litres (1.80 gallons)
- Overall Width
- 680 mm (26.8 inches)
- Overall Height
- 1,150 mm (45.3 inches)
- Overall Length
- 1,860 mm (73.2 inches)
- Power Weight Ratio
- 0.0527 HP/kg
- Rear Tyre
- 130/60-13
- Front Tyre
- 120/60-13
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Hydraulic monoshock
- Front Suspension
- Telescopic fork
Available colors
Red/white
