Back to Bike FinderYears: 1977
1977Scooter
Puch Maxi Sport
Key specifications
Engine
49 cc
Power
2 HP
Torque
2 Nm
Weight
39 kg
Fuel type
petrol
Seat height
19 mm
Front brakes
Expanding brake (drum brake)
Rear brakes
Expanding brake (drum brake)
Technical details
Source specification data
- Make
- Puch
- Model
- Maxi Sport
- Category
- Scooter
- Power
- 1.50 HP (1.1 kW)) @ 4500 RPM
- Torque
- 2.08 Nm (0.2 kgf-m or 1.5 ft.lbs) @ 3000 RPM
- Top Speed
- 40.2 km/h (25.0 mph)
- Bore X Stroke
- 38.0 x 43.0 mm (1.5 x 1.7 inches)
- Compression
- 9.2:1
- Displacement
- 48.80 ccm (2.98 cubic inches)
- Cooling System
- Air
- Engine Details
- Single cylinder, two-stroke
- Dry Weight
- 39.0 kg (86.0 pounds)
- Seat Height
- 483 mm (19.0 inches) If adjustable, lowest setting.
- Overall Width
- 690 mm (27.2 inches)
- Overall Height
- 1,000 mm (39.4 inches)
- Overall Length
- 1,700 mm (66.9 inches)
- Ground Clearance
- 100 mm (3.9 inches)
- Power Weight Ratio
- 0.0385 HP/kg
- Alternate Seat Height
- 533 mm (21.0 inches) If adjustable, highest setting.
- Rear Tyre
- 2/0-17
- Front Tyre
- 2/0-17
- Rear Brakes
- Expanding brake (drum brake)
- Front Brakes
- Expanding brake (drum brake)
