Back to Bike FinderYears: 2013 · 2010
2013ATV
Qlink Rodeo 500
$5,299
Key specifications
Engine
471 cc
Power
23 HP
Weight
328 kg
Fuel type
petrol
Fuel capacity
4.4 L
Transmission
Automatic
Seat height
34 mm
Front brakes
Single disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Qlink
- Model
- Rodeo 500
- Price
- S
- $ 5299.
- Prices
- depend on country, taxes, accessories, etc.
- Category
- ATV
- Starter
- Electric & kick
- Comments
- D
- /4
- D
- .
- T
- with
- L
- -
- H
- -
- N
- -
- R
- -
- P
- .
- Winch
- .
- Instruments
- Digital
- Color Options
- Red, camo
- Factory Warranty
- 1 Year Limited
- Power
- 22.80 HP (16.6 kW))
- Gearbox
- Automatic
- Driveline
- 4WD and differential lock
- Fuel System
- Carburettor. PD33J-A
- Bore X Stroke
- 84.5 x 84.0 mm (3.3 x 3.3 inches)
- Compression
- 9.4:1
- Displacement
- 471.00 ccm (28.74 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Transmission Type Final Drive
- Shaft drive (cardan)
- Dry Weight
- 327.5 kg (722.0 pounds)
- Seat Height
- 861 mm (33.9 inches) If adjustable, lowest setting.
- Fuel Capacity
- 16.65 litres (4.40 gallons)
- Overall Width
- 1,120 mm (44.1 inches)
- Overall Height
- 1,214 mm (47.8 inches)
- Overall Length
- 2,230 mm (87.8 inches)
- Ground Clearance
- 257 mm (10.1 inches)
- Power Weight Ratio
- 0.0696 HP/kg
- Rear Tyre
- 25/10-12
- Front Tyre
- 25/8-12
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Independent Double A-Arm
- Front Suspension
- Independent Double A-Arm
Available colors
Redcamo
