Back to Bike FinderYears: 2014
2014Allround
Quadro AATW R
Key specifications
Engine
346 cc
Power
27 HP
Weight
200 kg
Fuel type
petrol
Fuel capacity
3.4 L
Seat height
31 mm
Front brakes
Single disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Quadro
- Model
- AATW R
- Category
- Allround
- Starter
- Electric
- Comments
- Windshield. Italian brand.
- Color Options
- Orange
- Power
- 27.00 HP (19.7 kW)) @ 8000 RPM
- Ignition
- electronic
- Fuel System
- Carburettor
- Displacement
- 346.00 ccm (21.11 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Dry Weight
- 200.0 kg (440.9 pounds)
- Seat Height
- 780 mm (30.7 inches) If adjustable, lowest setting.
- Fuel Capacity
- 13.00 litres (3.43 gallons)
- Overall Width
- 800 mm (31.5 inches)
- Overall Length
- 2,270 mm (89.4 inches)
- Power Weight Ratio
- 0.1350 HP/kg
- Wheels
- Two front wheels
- Rear Tyre
- 140/70-15
- Frame Type
- Steel tubes
- Front Tyre
- 110/80-14
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Dual shocks
- Front Suspension
- HTS system with two wheels
- Rear Brakes Diameter
- 256 mm (10.1 inches)
- Front Brakes Diameter
- 240 mm (9.4 inches)
Available colors
Orange
