Back to Bike FinderYears: 2012
2012Allround
ShineTime Ace 50
Key specifications
Engine
50 cc
Power
3 HP
Torque
3 Nm
Weight
78 kg
Fuel type
petrol
Fuel capacity
1.5 L
Transmission
4-speed
Seat height
29 mm
Front brakes
Single disc
Rear brakes
Expanding brake (drum brake)
Technical details
Source specification data
- Make
- ShineTime
- Model
- Ace 50
- Category
- Allround
- Starter
- Electric & kick
- Comments
- Chinese model.
- Color Options
- Red, black
- Power
- 3.08 HP (2.2 kW)) @ 7500 RPM
- Clutch
- Wet, Multiple Disc
- Torque
- 2.90 Nm (0.3 kgf-m or 2.1 ft.lbs) @ 5000 RPM
- Gearbox
- 4-speed
- Ignition
- CDI
- Fuel System
- Carburettor
- Bore X Stroke
- 39.0 x 39.0 mm (1.5 x 1.5 inches)
- Compression
- 9.0:1
- Displacement
- 49.50 ccm (3.02 cubic inches)
- Cooling System
- Air
- Engine Details
- Single cylinder, four-stroke
- Lubrication System
- Pressure and splash lubrication
- Transmission Type Final Drive
- Chain
- Dry Weight
- 78.0 kg (172.0 pounds)
- Seat Height
- 740 mm (29.1 inches) If adjustable, lowest setting.
- Fuel Capacity
- 5.50 litres (1.45 gallons)
- Overall Width
- 680 mm (26.8 inches)
- Overall Height
- 990 mm (39.0 inches)
- Overall Length
- 1,640 mm (64.6 inches)
- Ground Clearance
- 200 mm (7.9 inches)
- Power Weight Ratio
- 0.0395 HP/kg
- Rear Tyre
- 3.00-18
- Frame Type
- Steel tube
- Front Tyre
- 2.75-18
- Rear Brakes
- Expanding brake (drum brake)
- Front Brakes
- Single disc
- Rear Suspension
- Dual shocks
- Front Suspension
- Telescopic forks
Available colors
Redblack
