Back to Bike FinderYears: 2014
2014Minibike
Skyteam ST125 Skymax
Key specifications
Engine
124 cc
Power
7 HP
Torque
7 Nm
Weight
78 kg
Fuel type
petrol
Transmission
4-speed
Seat height
29 mm
Front brakes
Single disc
Rear brakes
Expanding brake (drum brake)
Technical details
Source specification data
- Make
- Skyteam
- Model
- ST125 Skymax
- Category
- Minibike-cross
- Starter
- Electric & kick
- Comments
- Chinese brand.
- Color Options
- Black, red, blue, yellow
- Power
- 6.71 HP (4.9 kW)) @ 5500 RPM
- Torque
- 7.30 Nm (0.7 kgf-m or 5.4 ft.lbs) @ 6500 RPM
- Gearbox
- 4-speed
- Ignition
- CDI
- Top Speed
- 89.0 km/h (55.3 mph)
- Fuel System
- Carburettor
- Compression
- 9.0:1
- Displacement
- 124.00 ccm (7.57 cubic inches)
- Cooling System
- Air
- Engine Details
- Single cylinder, four-stroke
- Lubrication System
- Pressure and splash lubrication
- Transmission Type Final Drive
- Chain
- Dry Weight
- 78.0 kg (172.0 pounds)
- Seat Height
- 740 mm (29.1 inches) If adjustable, lowest setting.
- Overall Width
- 620 mm (24.4 inches)
- Overall Height
- 950 mm (37.4 inches)
- Overall Length
- 1,550 mm (61.0 inches)
- Ground Clearance
- 200 mm (7.9 inches)
- Power Weight Ratio
- 0.0860 HP/kg
- Rear Tyre
- 3.50-10
- Frame Type
- Steel, Single-tube
- Front Tyre
- 3.50-10
- Rear Brakes
- Expanding brake (drum brake)
- Front Brakes
- Single disc
- Rear Suspension
- Spring and oil double shocks
- Front Suspension
- Spring and oil fork
- Front Brakes Diameter
- 155 mm (6.1 inches)
Available colors
Blackredblueyellow
