Back to Bike FinderYears: 2023
2023Off-road
TM Racing EN 250 Fi ES 2T
Key specifications
Fuel type
petrol
Fuel capacity
2.3 L
Transmission
5-speed
Seat height
39 mm
Front brakes
Single disc. Wave disk with Nissin pump and Brembo caliper
Rear brakes
Single disc. Wave disk with Nissin pump and caliper
Technical details
Source specification data
- Make
- TM Racing
- Model
- EN 250 Fi ES 2T
- Category
- Enduro-offroad
- Starter
- Electric
- Comments
- Italian made bike.
- Color Options
- Blue/white
- Clutch
- Multiuple-disk in oil-bath with hydaulic control
- Gearbox
- 5-speed
- Ignition
- eMotion ECU
- Driveline
- Straight – tooth gear
- Fuel System
- Carburettor. Keihin PWK 38
- Bore X Stroke
- 66.4 x 72.0 mm (2.6 x 2.8 inches)
- Cooling System
- Liquid
- Engine Details
- V-Force Reed Valve
- Lubrication System
- 3.5% oil mix
- Transmission Type Final Drive
- Chain (final drive)
- Seat Height
- 985 mm (38.8 inches) If adjustable, lowest setting.
- Fuel Capacity
- 8.50 litres (2.25 US gallons)
- Ground Clearance
- 365 mm (14.4 inches)
- Rake
- 27.0°
- Wheels
- Wire spoked, blue rims
- Rear Tyre
- 140/80-18
- Frame Type
- Self-tempering aluminium deltabox type single beam with extruded, forged and microcast parts
- Front Tyre
- 90/90-21
- Rear Brakes
- Single
- disc.
- Wave
- disk with
- Nissin
- pump and caliper
- Front Brakes
- Single
- disc.
- Wave
- disk with
- Nissin
- pump and
- Brembo
- caliper
- Rear Suspension
- TM Racing monoshock
- Front Suspension
- Kayaba USD 48mm
- Rear Wheel Travel
- 300 mm (11.8 inches)
- Front Wheel Travel
- 310 mm (12.2 inches)
- Rear Brakes Diameter
- 245 mm (9.6 inches)
- Front Brakes Diameter
- 270 mm (10.6 inches)
Available colors
Blue/white
