2016Off-road
TM Racing MX 530F
Key specifications
Engine
528 cc
Fuel type
petrol
Fuel capacity
2.2 L
Transmission
5-speed
Front brakes
Single disc. Wave disk with Nissin pump and Brembo caliper
Rear brakes
Single disc. Wave disk with Nissin pump and caliper
Technical details
Source specification data
- Make
- TM Racing
- Model
- MX 530F
- Category
- Cross-motocross
- Starter
- Kick
- Comments
- Optional electric start. Italian brand.
- Color Options
- Blue/white
- Clutch
- Multiple-disk in oil-bath with hydraulic control
- Gearbox
- 5-speed
- Ignition
- Kokusan DCI Electronic with variable advance
- Driveline
- Straight, tooth gear
- Engine Type
- Titanium valves
- Fuel System
- Carburettor. Keihin 41 mm
- Bore X Stroke
- 98.0 x 70.0 mm (3.9 x 2.8 inches)
- Displacement
- 528.00 ccm (32.22 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Lubrication System
- Dry sump with 2 pumps
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Fuel Capacity
- 8.20 litres (2.17 gallons)
- Wheels
- Wire spoked
- Rear Tyre
- 140/80-19
- Frame Type
- Alluminium perimetral
- Front Tyre
- 90/90-21
- Rear Brakes
- Single
- disc.
- Wave
- disk with
- Nissin
- pump and caliper
- Front Brakes
- Single
- disc.
- Wave
- disk with
- Nissin
- pump and
- Brembo
- caliper
- Rear Suspension
- Sachs (optional TM Racing)
- Front Suspension
- D
- 45 mm (optional
- D
- 50 mm)
- Rear Brakes Diameter
- 245 mm (9.6 inches)
- Front Brakes Diameter
- 270 mm (10.6 inches)
Available colors
Blue/white
