Back to Bike FinderYears: 2016
2016Naked
Triumph Speed Triple RX
Key specifications
Engine
675 cc
Power
106 HP
Torque
68 Nm
Weight
168 kg
Fuel type
petrol
Fuel capacity
4.6 L
Transmission
6-speed
Seat height
32 mm
Front brakes
Double disc. Nissin 4-piston radial calipers. Switchable ABS.
Rear brakes
Single disc. Bremo single piston caliper. Switchable ABS.
Technical details
Source specification data
- Make
- Triumph
- Model
- Speed Triple RX
- Category
- Naked bike
- Starter
- Electric
- Comments
- Special edition.
- Instruments
- LCD multi-functional instruments
- Color Options
- Jet Black, Diablo Red/Matt Aluminium Silver
- Factory Warranty
- 2 year warranty unlimited mileage
- Power
- 106.00 HP (77.4 kW)) @ 11850 RPM
- Clutch
- Wet. multi-plate
- Torque
- 68.00 Nm (6.9 kgf-m or 50.2 ft.lbs) @ 9750 RPM
- Gearbox
- 6-speed
- Driveline
- O ring chain
- Fuel System
- Injection
- .
- Multipoint
- sequential electronic fuel injection with
- Bore X Stroke
- 74.0 x 52.3 mm (2.9 x 2.1 inches)
- Compression
- 12.8:1
- Displacement
- 675.00 ccm (41.19 cubic inches)
- Cooling System
- Liquid
- Engine Details
- In-line three, four-stroke
- Exhaust System
- Stainless Steel 3 into 1 into 2. twin high level stainless steel pipes.
- Fuel Consumption
- 6.92 litres/100 km (14.5 km/l or 33.99 mpg)
- Greenhouse Gases
- O2
- g/km. (
- O2
- -
- Carbon
- dioxide emission)
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Dry Weight
- 168.0 kg (370.4 pounds)
- Seat Height
- 820 mm (32.3 inches) If adjustable, lowest setting.
- Oil Capacity
- 3.80 litres (0.25 quarts)
- Fuel Capacity
- 17.50 litres (4.62 gallons)
- Overall Width
- 740 mm (29.1 inches)
- Overall Height
- 1,110 mm (43.7 inches)
- Overall Length
- 2,100 mm (82.7 inches)
- Power Weight Ratio
- 0.6310 HP/kg
- Rake
- 23.4°
- Trail
- 95 mm (3.7 inches)
- Wheels
- Cast aluminium alloy 5-spoke
- Rear Tyre
- 180/55-ZR17
- Frame Type
- Aluminum
- beam twin-spar.
- Single
- -sided, aluminum alloy with eccentric chain adjuster swing arm.
- Front Tyre
- 120/70-ZR17
- Rear Brakes
- Single
- disc.
- Bremo
- single piston caliper.
- S
- .
- Front Brakes
- Double
- disc.
- Nissin
- 4-piston radial calipers.
- S
- .
- Rear Suspension
- Kayaba monoshock with piggy back reservoir adjustable for rebound and compression damping
- Front Suspension
- Kayaba 41 mm upside down forks with adjustable preload, rebound and compression damping
- Rear Wheel Travel
- 135 mm (5.3 inches)
- Front Wheel Travel
- 115 mm (4.5 inches)
- Rear Brakes Diameter
- 255 mm (10.0 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
Jet BlackDiablo Red/Matt Aluminium Silver
