Back to Bike FinderYears: 2007
2007Classic
TVS Victor Edge
Key specifications
Engine
125 cc
Power
9 HP
Torque
10 Nm
Weight
117 kg
Fuel type
petrol
Fuel capacity
2.9 L
Transmission
4-speed
Front brakes
Single disc
Rear brakes
Expanding brake (drum brake)
Technical details
Source specification data
- Make
- TVS
- Model
- Victor Edge
- Category
- Classic
- Starter
- Kick
- Color Options
- Red Gold
- ,
- Black Blue
- ,
- Blue Gold
- ,
- Silver Blue
- ,
- Power
- 9.07 HP (6.6 kW)) @ 7000 RPM
- Torque
- 10.00 Nm (1.0 kgf-m or 7.4 ft.lbs) @ 4000 RPM
- Gearbox
- 4-speed
- Bore X Stroke
- 54.5 x 53.5 mm (2.1 x 2.1 inches)
- Displacement
- 124.80 ccm (7.62 cubic inches)
- Cooling System
- Air
- Engine Details
- Single cylinder, four-stroke
- Dry Weight
- 117.0 kg (257.9 pounds)
- Fuel Capacity
- 11.00 litres (2.91 gallons)
- Overall Width
- 700 mm (27.6 inches)
- Overall Length
- 2,002 mm (78.8 inches)
- Ground Clearance
- 165 mm (6.5 inches)
- Power Weight Ratio
- 0.0775 HP/kg
- Rear Tyre
- 40/60-90
- Front Tyre
- 40/60-90
- Rear Brakes
- Expanding brake (drum brake)
- Front Brakes
- Single disc
- Rear Suspension
- S3 Shock Absorbers
- ,
- Co
- -axial
- Spring
- with 5
- Step Adjustable Preload
- , 75 mm at
- Front Suspension
- Telescopic Oil
- -
- Damped
- , 105 mm
- Rear Wheel Travel
- 75 mm (3.0 inches)
- Front Wheel Travel
- 105 mm (4.1 inches)
- Rear Brakes Diameter
- 130 mm (5.1 inches)
- Front Brakes Diameter
- 240 mm (9.4 inches)
Available colors
Red GoldBlack BlueBlue GoldSilver BlueBlack Copper
