UM Arrow 150
2019Scooter

UM Arrow 150

Key specifications

Engine
150 cc
Weight
120 kg
Fuel type
petrol
Fuel capacity
2.5 L
Front brakes
Single disc
Rear brakes
Single disc

Technical details

Source specification data

Make
UM
Model
Arrow 150
Category
Scooter
Starter
Electric & kick
Fuel System
Carburettor
Bore X Stroke
57.4 x 57.7 mm (2.3 x 2.3 inches)
Compression
9.2:1
Displacement
149.60 ccm (9.13 cubic inches)
Cooling System
Air
Engine Details
Single cylinder, four-stroke
Dry Weight
120.2 kg (265.0 pounds)
Fuel Capacity
9.46 litres (2.50 gallons)
Overall Width
813 mm (32.0 inches)
Overall Height
1,372 mm (54.0 inches)
Overall Length
2,032 mm (80.0 inches)
Front Tyre
110/90-12
Rear Brakes
Single disc
Front Brakes
Single disc
Front Brakes Diameter
216 mm (8.5 inches)
