Back to Bike FinderYears: 2012
2012Cruiser
Victory High Ball
$13,499
Key specifications
Engine
1737 cc
Power
97 HP
Torque
153 Nm
Weight
299 kg
Fuel type
petrol
Fuel capacity
4.5 L
Transmission
6-speed
Seat height
25 mm
Front brakes
Double disc. Floating rotor with 4-piston calipers
Rear brakes
Single disc. Floating rotor with 2-piston caliper
Technical details
Source specification data
- Make
- Victory
- Model
- High Ball
- Price
- S
- $ 13499.
- Prices
- depend on country, taxes, accessories, etc.
- Category
- Custom-cruiser
- Starter
- Electric
- Electrical
- 12 volts / 18 amp hours battery.
- Color Options
- Suede Black w/graphics
- Power
- 97.00 HP (70.8 kW))
- Clutch
- Wet, Multi-plate
- Torque
- 153.23 Nm (15.6 kgf-m or 113.0 ft.lbs)
- Gearbox
- 6-speed
- Driveline
- Carbon Fiber Reinforced Belt
- .
- Primary
- drive:
- Gear
- drive with torque compensator.
- Engine Type
- V
- -
- Twin
- .
- Self
- -adjusting cam chains, hydraulic lifters.
- Fuel System
- Injection
- .
- Electronic Fuel Injection
- with dual 45mm throttle body
- Bore X Stroke
- 101.0 x 108.0 mm (4.0 x 4.3 inches)
- Compression
- 9.4:1
- Displacement
- 1737.14 ccm (106.00 cubic inches)
- Cooling System
- Oil & air
- Engine Details
- V2, four-stroke
- Exhaust System
- Staggered slash-cut dual exhaust with crossover
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Belt
- Dry Weight
- 298.9 kg (659.0 pounds)
- Seat Height
- 635 mm (25.0 inches) If adjustable, lowest setting.
- Oil Capacity
- 4.70 litres (0.31 quarts)
- Fuel Capacity
- 17.03 litres (4.50 gallons)
- Overall Length
- 2,350 mm (92.5 inches)
- Ground Clearance
- 119 mm (4.7 inches)
- Power Weight Ratio
- 0.3245 HP/kg
- Rake
- 31.7°
- Wheels
- Old-school lace design with white sidewalls
- Rear Tyre
- 150/80-H16
- Front Tyre
- 130/90-H16
- Rear Brakes
- Single
- disc.
- Floating
- rotor with 2-piston caliper
- Front Brakes
- Double
- disc.
- Floating
- rotor with 4-piston calipers
- Rear Suspension
- Single, mono-tube gas, cast aluminum with rising rate linkage, 3.0 in / 75 mm travel, preload adjustable spring
- Front Suspension
- Conventional telescopic fork, 43 mm diameter, 5.1 in / 130 mm travel
- Rear Brakes Diameter
- 300 mm (11.8 inches)
- Front Brakes Diameter
- 300 mm (11.8 inches)
Available colors
Suede Black w/graphics
