Victory Ness Signature Series Jackpot
2006Cruiser

Victory Ness Signature Series Jackpot

Key specifications

Engine
1639 cc
Weight
292 kg
Fuel type
petrol
Fuel capacity
4.5 L
Transmission
6-speed
Seat height
26 mm
Front brakes
Single disc
Rear brakes
Single disc

Technical details

Source specification data

Make
Victory
Model
Ness Signature Series Jackpot
Category
Custom-cruiser
Color Options
Arlen
-
Graphic
,
Cory
-
Black
with
Clutch
Wet, Multi-plate
Gearbox
6-speed
Fuel System
Injection
.
Electronic Fuel Injection
with 44 mm throttle bodies
Bore X Stroke
101.0 x 102.0 mm (4.0 x 4.0 inches)
Compression
9.8:1
Displacement
1638.81 ccm (100.00 cubic inches)
Cooling System
Air
Engine Details
V2, four-stroke
Exhaust System
Staggered slash-cut dual exhaust with common volume
Valves Per Cylinder
4
Transmission Type Final Drive
Belt
Dry Weight
292.1 kg (644.0 pounds)
Seat Height
653 mm (25.7 inches) If adjustable, lowest setting.
Fuel Capacity
17.03 litres (4.50 gallons)
Overall Length
2,446 mm (96.3 inches)
Ground Clearance
135 mm (5.3 inches)
Rake
33.5°
Rear Tyre
250/40-B18
Front Tyre
80/90-21
Rear Brakes
Single disc
Front Brakes
Single disc
Rear Suspension
Single, mono-tube gas, forged and cast aluminum with rising rate linkage swing-arm, 3.0in/75mm travel, preload adjustable spring
Front Suspension
Conventional telescopic fork, 43 mm diameter, 5.1in/130mm travel
Rear Brakes Diameter
300 mm (11.8 inches)
Front Brakes Diameter
300 mm (11.8 inches)

Available colors

Arlen-Supersonic Blue/GraphicCory-Black with Blue Flames
