Voge Trofeo 525ACX
Key specifications
Engine
494 cc
Torque
45 Nm
Weight
170 kg
Fuel type
petrol
Fuel capacity
5.0 L
Transmission
6-speed
Seat height
33 mm
Front brakes
Double disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Voge
- Model
- Trofeo 525ACX
- Category
- Allround
- Light
- LED
- Starter
- Electric
- Comments
- Chinese made bike. Sold in Italy.
- Instruments
- TFT Colour Display
- Color Options
- Black, grey
- Torque
- 44.5 Nm (4.5 kgf-m or 32.8 ft.lbs) @ 7000 RPM
- Gearbox
- 6-speed
- Top Speed
- 128.0 km/h (79.5 mph)
- Engine Type
- Twin, four-stroke
- Fuel System
- Injection
- Compression
- 11.5:1
- Displacement
- 494.0 ccm (30.14 cubic inches)
- Cooling System
- Liquid
- Emission Details
- Euro 5
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain (final drive)
- Dry Weight
- 170.0 kg (374.8 pounds)
- Seat Height
- 845 mm (33.3 inches) If adjustable, lowest setting.
- Fuel Capacity
- 19.00 litres (5.02 US gallons)
- Overall Width
- 820 mm (32.3 inches)
- Overall Height
- 1230 mm (48.4 inches)
- Overall Length
- 2150 mm (84.6 inches)
- Ground Clearance
- 200 mm (7.9 inches)
- Power Weight Ratio
- 0.2759 HP/kg
- Rear Tyre
- 150/70-17
- Front Tyre
- 110/80-19
- Rear Brakes
- Single disc
- Front Brakes
- Double disc
- Rear Suspension
- Monoshock, adjustable
- Front Suspension
- Kayba upside down forks, 35 mm
Available colors
Blackgrey
