Back to Bike FinderYears: 2007
2007Super Moto
VOR SM-RC 570 Supermotard
Key specifications
Engine
569 cc
Weight
109 kg
Fuel type
petrol
Fuel capacity
1.5 L
Transmission
5-speed
Front brakes
Single disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- VOR
- Model
- SM-RC 570 Supermotard
- Category
- Super motard
- Starter
- Kick
- Clutch
- Discs in oil bath, hydraulic control
- Gearbox
- 5-speed
- Ignition
- SEM electronic
- Fuel System
- Carburettor. Keihin FCR 41
- Bore X Stroke
- 97.0 x 71.0 mm (3.8 x 2.8 inches)
- Compression
- 11.0:1
- Displacement
- 569.00 ccm (34.72 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Dry Weight
- 109.0 kg (240.3 pounds)
- Fuel Capacity
- 5.50 litres (1.45 gallons)
- Rear Tyre
- 160/60-17
- Frame Type
- Perimeter
- in molybdenum chrome-plated steel.
- Rear
- mini-frame in aluminium.
- Front Tyre
- 120/70-17
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Single
- shock absorber on graduated system.
- Pre
- -loading adjustment, extension, compression
- Front Suspension
- Fork
- with inverted ø 46 mm rods.
- Pre
- -loading, extension, compression
- Rear Wheel Travel
- 275 mm (10.8 inches)
- Front Wheel Travel
- 275 mm (10.8 inches)
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
