Vuka XL 125
1976Allround

Vuka XL 125

Key specifications

Engine
124 cc
Power
13 HP
Fuel type
petrol
Fuel capacity
1.6 L
Transmission
5-speed
Front brakes
Expanding brake
Rear brakes
Expanding brake

Overview

Introducing the 1976 Honda XL 125, a remarkable entry into the world of enduro and off-road motorcycles. As the quintessential lightweight trail bike, the XL 125 was designed for riders seeking both adventure and agility. With its compact frame and robust engineering, Honda positioned the XL 125 to appeal to both novice riders and experienced enthusiasts looking for a reliable companion on rugged paths and casual rides alike. Its blend of practicality and performance helped it carve out a dedicated following in an era when off-road biking was gaining momentum. At the heart of the XL 125 lies a nimble single-cylinder, four-stroke engine with a displacement of 124 ccm. This powerplant delivers a respectable 13 horsepower at a thrilling 9,400 RPM, propelling the bike to a top speed of 114 km/h (70.8 mph). The air-cooled engine is designed to withstand the rigors of off-road adventures, while its 9.4:1 compression ratio and compact bore and stroke dimensions (56.5 mm x 49.5 mm) contribute to its lively performance. Coupled with a 5-speed gearbox and a chain final drive, the XL 125 offers smooth shifting and responsive acceleration, making it a joy to navigate through trails or tackle steep inclines. The XL 125 is equipped with practical features that enhance its usability and durability. The expanding brake system on both the front and rear ensures dependable stopping power, whether you're navigating rocky terrain or cruising through the city. Weighing in at just 110 kg (242.5 pounds), the bike boasts an impressive power-to-weight ratio, allowing for easy handling and maneuverability. The 6-liter fuel tank provides just the right capacity for longer rides without compromising on weight, ensuring you can venture further into the wilderness without constant stops for refueling. **

Pros

  • Lightweight Design: At just 110 kg, the XL 125 is easy to handle, making it a great choice for new riders and those looking for a nimble off-road experience.
  • Reliable Engine: The single-cylinder, four-stroke engine offers a good balance of power and efficiency, ideal for both trail riding and commuting.
  • Versatile Performance: With a 5-speed gearbox and solid suspension, the XL 125 is well-suited for various terrains, from dirt trails to urban streets.

Cons

  • Limited Power: While adequate for casual riding, the 13 HP engine may feel underwhelming for more experienced riders seeking high-performance thrills.
  • Basic Features: The XL 125 lacks modern amenities and technology, which could deter riders looking for advanced features like fuel injection or digital displays.
  • Small Fuel Tank: The 6-liter tank may require more frequent refueling on longer journeys, which could be a drawback for those venturing deep into the backcountry.

Technical details

Source specification data

Make
Honda
Model
XL 125
Category
Enduro-offroad
Power
13.00 HP (9.5 kW)) @ 9400 RPM
Gearbox
5-speed
Top Speed
114.0 km/h (70.8 mph)
Bore X Stroke
56.5 x 49.5 mm (2.2 x 1.9 inches)
Compression
9.4:1
Displacement
124.00 ccm (7.57 cubic inches)
Cooling System
Air
Engine Details
Single cylinder, four-stroke
Valves Per Cylinder
2
Transmission Type Final Drive
Chain
Fuel Capacity
6.00 litres (1.59 gallons)
Weight Incl Oil Gas Etc
110.0 kg (242.5 pounds)
Rear Tyre
3.50-18
Front Tyre
2.75-21
Rear Brakes
Expanding brake
Front Brakes
Expanding brake
