KTM 690 SMC R
2012Super Moto

KTM 690 SMC R

Key specifications

Engine
690 cc
Power
66 HP
Torque
64 Nm
Weight
142 kg
Fuel type
petrol
Fuel capacity
3.2 L
Transmission
6-speed
Seat height
36 mm
Front brakes
Single disc
Rear brakes
Single disc

Overview

Introducing the 2012 KTM 690 SMC R, a fierce contender in the supermoto category that captures the essence of spirited riding. This machine is not just a bike; it’s a statement of purpose for enthusiasts who crave performance on both urban streets and winding backroads. With KTM’s rich racing heritage, the 690 SMC R stands out with its striking design and aggressive stance, showcasing the brand's commitment to delivering high-performance motorcycles that push the boundaries of what’s possible. At the heart of the 690 SMC R lies a robust 690cc single-cylinder, four-stroke engine that delivers a thrilling 66 horsepower at 7,500 RPM and a hearty 64 Nm of torque at 6,000 RPM. This powerplant provides exhilarating acceleration, making every twist of the throttle an adventure. The lightweight frame, tipping the scales at just 142 kg (313.1 lbs), coupled with a 6-speed gearbox, ensures that this bike is nimble and responsive, carving through corners with confidence and precision. Riders will appreciate the liquid cooling system that maintains optimal engine temperature, and the sensitive throttle response makes it a joy to ride at any speed. The 690 SMC R is packed with advanced technology and features that enhance both performance and rider comfort. Its tubular space frame, crafted from chrome molybdenum steel, is designed for optimal handling and stability. The WP Suspension—both front and rear—provides an impressive 250 mm of travel, ensuring a smooth ride over any terrain. The braking system features powerful single discs at both ends, with a 320 mm diameter at the front for superior stopping power. Add to this the APTC anti-hopping clutch, and you have a machine that is as responsive as it is forgiving, making it perfect for both seasoned riders and those new to the supermoto scene. **

Pros

  • Lightweight and Agile: Weighing in at just 142 kg makes the 690 SMC R incredibly nimble, allowing for easy maneuverability in tight spaces and sharp corners.
  • Powerful Engine Performance: The single-cylinder engine delivers strong acceleration and torque, making it a blast to ride both in the city and on twisty roads.
  • High-Quality Suspension: With 250 mm of travel and premium WP components, the suspension absorbs bumps effortlessly, providing a comfortable riding experience.

Cons

  • Seat Height: At 925 mm, the seat height may be challenging for shorter riders, limiting accessibility for some.
  • Limited Fuel Capacity: With a fuel tank capacity of just 12 liters, frequent refueling may be necessary, especially on longer rides.
  • Carburettor Fuel System: While it contributes to the bike's performance character, the carburettor setup may require more frequent tuning and maintenance compared to modern fuel injection systems.

Technical details

Source specification data

Make
KTM
Model
690 SMC R
Category
Super motard
Starter
Electric
Color Options
Black/orange/white
Power
66.00 HP (48.2 kW)) @ 7500 RPM
Clutch
APTC Anti-hopping clutch / hydraulically operated
Torque
64.00 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 6000 RPM
Gearbox
6-speed
Ignition
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Driveline
16:42. Primary drive: 36:79.
Fuel System
Carburettor
Bore X Stroke
102.0 x 84.5 mm (4.0 x 3.3 inches)
Compression
11.8:1
Displacement
690.00 ccm (42.10 cubic inches)
Cooling System
Liquid
Engine Details
Single cylinder, four-stroke
Lubrication System
Semi-dry-sump lubrication with 2 rotor pumps
Transmission Type Final Drive
Chain
Dry Weight
142.0 kg (313.1 pounds)
Seat Height
925 mm (36.4 inches) If adjustable, lowest setting.
Fuel Capacity
12.00 litres (3.17 gallons)
Ground Clearance
270 mm (10.6 inches)
Power Weight Ratio
0.4648 HP/kg
Rake
27.0°
Trail
112 mm (4.4 inches)
Rear Tyre
160/60-ZR17
Frame Type
Tubular space frame made from chrome molybdenum steel, powder-coated
Front Tyre
120/70-17
Rear Brakes
Single disc
Front Brakes
Single disc
Rear Suspension
P Suspension
4618 with
Pro
and #8209;
Lever
linkage
Front Suspension
WP Suspension Up Side Down 4860 ROMA
Rear Wheel Travel
250 mm (9.8 inches)
Front Wheel Travel
250 mm (9.8 inches)
Rear Brakes Diameter
240 mm (9.4 inches)
Front Brakes Diameter
320 mm (12.6 inches)

Available colors

Black/orange/white
