KTM SX 125
2022Super Moto

KTM SX 125

Key specifications

Engine
125 cc
Power
15 HP
Torque
11 Nm
Fuel type
petrol
Fuel capacity
1.9 L
Transmission
6-speed
Seat height
35 mm
Front brakes
Single disc. Floating calliper
Rear brakes
Single disc. Floating calliper

Overview

Introducing the 2022 KTM SX 125, a striking super motard that redefines the entry-level segment for aspiring riders and weekend warriors alike. With its aggressive styling and nimble handling, the SX 125 is not just a motorcycle; it’s a gateway to the exhilarating world of off-road racing and urban exploration. Designed for younger riders and those new to the sport, this model perfectly balances performance and accessibility, making it an ideal choice for those eager to make their mark on the track or the streets. At the heart of the SX 125 is a spirited 124.8 ccm engine that delivers an impressive 15 horsepower at a thrilling 10,000 RPM. This high-revving, liquid-cooled powerplant produces 11.2 Nm of torque, ensuring a responsive ride that’s both exhilarating and manageable. The 6-speed gearbox allows for seamless gear changes, while the multi-plate wet clutch ensures smooth engagement and disengagement, making the bike user-friendly for novice riders. With a fuel consumption of just 2.60 liters per 100 km, the SX 125 not only offers spirited performance but also remarkable efficiency, allowing riders to enjoy longer rides without the constant worry of refueling. Packed with features and cutting-edge technology, the 2022 KTM SX 125 stands out with its robust twin-tube steel frame and high-quality suspension components. The front boasts an upside-down fork with 41 mm stanchions, providing 240 mm of travel for exceptional handling over rough terrain, while the rear suspension’s monoshock design offers 210 mm of travel for a plush ride. Stopping power comes from a 300 mm front disc and a 220 mm rear disc, ensuring confidence-inspiring braking performance. With a seat height of 880 mm and a lightweight frame tipping the scales at just 134 kg, the SX 125 caters to a wide range of rider heights and abilities, making it a versatile choice for those looking to hone their skills or simply enjoy the ride. **

Pros

  • Lightweight and Agile: At just 134 kg, the SX 125 offers excellent maneuverability, making it perfect for tight corners and urban riding.
  • Fuel Efficient: With a consumption rate of 2.60 liters per 100 km, riders can enjoy longer journeys without frequently stopping to refuel.
  • High-Revving Engine: The powerful engine delivers impressive performance, allowing for both spirited rides and a playful experience on the track.

Cons

  • Limited Power for Experienced Riders: While great for beginners, more seasoned riders may find the 15 HP limiting for serious competition.
  • Seat Height: The 880 mm seat height might be challenging for shorter riders, potentially impacting their confidence and control.
  • Single Disc Brakes: Though effective, the single disc setup might not provide the same level of performance as more advanced dual-disc configurations found in higher-end models.

Technical details

Source specification data

Make
Aprilia
Model
SX 125
Category
Super motard
Starter
Electric
Instruments
Digital dashboard
Color Options
Red Raceway, Silver Speedway
Power
15.0 HP (10.9 kW)) @ 10000 RPM
Clutch
Multi Plate Wet
Torque
11.2 Nm (1.1 kgf-m or 8.3 ft.lbs) @ 8000 RPM
Ignition
ECU Electronics Magneti Marelli MIUG4 ø 32 mm
Driveline
Primary
drive:
Gearbox
: 63/19 (3.31).
Final
drive:
Chain
: 17/40 (2.35).
Engine Type
Single cylinder, four-stroke
Fuel System
Injection
Bore X Stroke
58.0 x 47.0 mm (2.3 x 1.9 inches)
Compression
12.6:1
Displacement
124.8 ccm (7.62 cubic inches)
Cooling System
Liquid
Emission Details
Euro 5
Fuel Consumption
2.60 litres/100 km (38.5 km/l or 90.47 mpg)
Greenhouse Gases
O2
g/km. (
O2
-
Carbon
dioxide emission)
Lubrication System
Wet sump
Transmission Type Final Drive
Chain (final drive)
Seat Height
880 mm (34.6 inches) If adjustable, lowest setting.
Fuel Capacity
7.00 litres (1.85 US gallons)
Overall Width
820 mm (32.3 inches)
Overall Height
1140 mm (44.9 inches)
Overall Length
2075 mm (81.7 inches)
Weight Incl Oil Gas Etc
134.0 kg (295.4 pounds)
Wheels
Aluminium spoked wheel.
Rear Tyre
130/70-R17
Frame Type
Twin-tube stee
Front Tyre
110/80-R17
Rear Brakes
Single disc. Floating calliper
Front Brakes
Single disc. Floating calliper
Rear Suspension
Steel swingarm, monoshock with progressive link system
Front Suspension
Upside down fork with Ø 41 mm stanchions.
Rear Wheel Travel
210 mm (8.3 inches)
Front Wheel Travel
240 mm (9.4 inches)
Rear Brakes Diameter
220 mm (8.7 inches)
Front Brakes Diameter
300 mm (11.8 inches)

Available colors

Red RacewaySilver Speedway
