2011Naked
Moto Morini 9 1-2
$10,870
Key specifications
Engine
1187 cc
Power
117 HP
Torque
102 Nm
Weight
198 kg
Fuel type
petrol
Fuel capacity
5.6 L
Transmission
6-speed
Seat height
32 mm
Front brakes
Double disc. Bremo, 4-piston calipers
Rear brakes
Single disc. Bremo, 2-piston calipers
Technical details
Source specification data
- Make
- Moto Morini
- Model
- 9 1-2
- Price
- Euro
- 10870.
- Prices
- depend on country, taxes, accessories, etc.
- Category
- Naked bike
- Starter
- Electric
- Comments
- Italian brand.
- Instruments
- Analgue/LCD
- Color Options
- Black/red, black/silver
- Factory Warranty
- 3 years
- Power
- 117.00 HP (85.4 kW)) @ 8500 RPM
- Clutch
- Wet, Multi-plate Type
- Torque
- 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 RPM
- Gearbox
- 6-speed
- Ignition
- I.A.W. electronic
- Engine Type
- 87 degree V-twin
- Fuel System
- Injection
- .
- Magneti Marelli
- indirect electronic injection with 54 mm throttle body
- Bore X Stroke
- 107.0 x 66.0 mm (4.2 x 2.6 inches)
- Displacement
- 1187.00 ccm (72.43 cubic inches)
- Cooling System
- Liquid
- Engine Details
- V2, four-stroke
- Exhaust System
- Silencer, 3-way catalytic converter with oxygen sensor.
- Emission Details
- Euro 3.
- Lubrication System
- Forced with trochoidal pump
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Dry Weight
- 198.0 kg (436.5 pounds)
- Seat Height
- 800 mm (31.5 inches) If adjustable, lowest setting.
- Fuel Capacity
- 21.00 litres (5.55 gallons)
- Overall Width
- 865 mm (34.1 inches)
- Overall Height
- 800 mm (31.5 inches)
- Overall Length
- 2,170 mm (85.4 inches)
- Ground Clearance
- 162 mm (6.4 inches)
- Power Weight Ratio
- 0.5909 HP/kg
- Reserve Fuel Capacity
- 4.50 litres (1.19 gallons)
- Rake
- 24.5°
- Trail
- 100 mm (3.9 inches)
- Rear Tyre
- 180/55-R17
- Frame Type
- Verlicchi high strength steel tube tellis frame
- Front Tyre
- 120/70-R17
- Rear Brakes
- Single disc. Bremo, 2-piston calipers
- Front Brakes
- Double disc. Bremo, 4-piston calipers
- Rear Suspension
- Single lateral shock absorber with fully adjustable pibby tank
- Front Suspension
- Marzocchi upside-down fork
- Rear Wheel Travel
- 150 mm (5.9 inches)
- Front Wheel Travel
- 150 mm (5.9 inches)
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
Black/redblack/silver
