KTM 450 SMR
2005Super Moto

KTM 450 SMR

Key specifications

Engine
449 cc
Torque
43 Nm
Weight
109 kg
Fuel type
petrol
Fuel capacity
1.9 L
Transmission
6-speed
Seat height
34 mm
Front brakes
Single disc
Rear brakes
Single disc

Overview

Introducing the 2005 KTM 450 SMR, a spirited contender in the supermotard category that perfectly blends off-road ruggedness with street-savvy agility. KTM, renowned for its competitive edge in the motocross world, brings its expertise into the urban realm with this model, designed for riders who crave the thrill of both dirt and asphalt. With its lightweight frame and aggressive styling, the 450 SMR stands as a versatile machine, ready to dominate twisty backroads or carve through city traffic with ease. At the heart of the 450 SMR lies a robust 449.4cc single-cylinder, four-stroke engine that packs a punch, delivering a commendable torque of 42.50 Nm at just 3250 RPM. This engine is not just about raw numbers; it’s the soul of the bike, providing smooth power delivery and responsive throttle control that keeps you connected to the road. With a high compression ratio of 12.0:1 and an advanced Keihin MX FCR 41 carburettor, the engine is tailored for performance enthusiasts who appreciate the exhilarating rush of a well-tuned machine. The six-speed gearbox enhances its versatility, allowing riders to effortlessly switch between aggressive acceleration and relaxed cruising, while the liquid cooling system keeps the engine performing optimally even under the toughest conditions. The 450 SMR is built with features that reflect KTM's racing pedigree, including a lightweight chromium molybdenum frame that contributes to its impressive handling and agility. The WP-USD front suspension with 48mm forks and the WP-PDS rear shock absorber provide superb damping and stability, making it ready to tackle both the racetrack and the urban jungle. The powerful braking system, featuring single discs of 320mm at the front and 310mm at the rear, ensures confidence-inspiring stopping power. With a seat height of 855mm and a ground clearance of 310mm, the bike is designed for a wide range of riders, providing a comfortable yet commanding riding position. **

Pros

  • Exceptional handling and agility, thanks to its lightweight frame and advanced suspension.
  • Powerful engine performance with smooth power delivery, ideal for both on and off-road adventures.
  • High-quality braking system that provides reliable stopping power in various riding conditions.

Cons

  • Limited fuel capacity of 7.00 litres may require more frequent stops on longer rides.
  • Kick starter may not appeal to all riders, especially in comparison to electric start options found on competitors.
  • Seat height may be challenging for shorter riders, limiting accessibility for some.

Technical details

Source specification data

Make
KTM
Model
450 SMR
Category
Super motard
Starter
Kick
Clutch
Wet multi-disc clutch, operated hydraulically
Torque
42.50 Nm (4.3 kgf-m or 31.3 ft.lbs) @ 3250 RPM
Gearbox
6-speed
Ignition
Kokusan digital 4K-3A
Fuel System
Carburettor. Keihin MX FCR 41
Bore X Stroke
95.0 x 63.4 mm (3.7 x 2.5 inches)
Compression
12.0:1
Displacement
449.40 ccm (27.42 cubic inches)
Cooling System
Liquid
Engine Details
Single cylinder, four-stroke
Lubrication System
Pressure lubrication with 2 Eaton pumps
Valves Per Cylinder
4
Transmission Type Final Drive
Chain
Dry Weight
108.5 kg (239.2 pounds)
Seat Height
855 mm (33.7 inches) If adjustable, lowest setting.
Fuel Capacity
7.00 litres (1.85 gallons)
Overall Width
450 mm (17.7 inches)
Ground Clearance
310 mm (12.2 inches)
Rake
26.5°
Trail
90 mm (3.5 inches)
Rear Tyre
160/60-17
Frame Type
chromium molybdenum
Front Tyre
120/70-17
Rear Brakes
Single disc
Front Brakes
Single disc
Rear Suspension
WP-PDS shock absorber
Front Suspension
WP-USD 48 mm (1.89´
Rear Wheel Travel
335 mm (13.2 inches)
Rear Brakes Diameter
310 mm (12.2 inches)
Front Brakes Diameter
320 mm (12.6 inches)
