KTM 450 SMR
Key specifications
Overview
Introducing the 2006 KTM 450 SMR, a powerhouse in the super motard category that expertly blends dirt bike agility with street-ready performance. Designed for the thrill-seeker who demands versatility, the 450 SMR is engineered to dominate both urban roads and off-road trails. With KTM’s legacy of innovation and performance at its core, this model exemplifies the brand's commitment to delivering machines that are as fun to ride as they are capable. Whether you’re navigating tight corners, tackling technical terrain, or simply enjoying a spirited ride through the city, the 450 SMR stands ready to impress. At the heart of the KTM 450 SMR lies a robust 449.4 cc single-cylinder, four-stroke engine that bursts with energy. With a torque output of 42.50 Nm at 3,250 RPM, this engine provides an exhilarating response, ensuring that every twist of the throttle is met with immediate acceleration. The 6-speed gearbox allows for smooth gear transitions, making it easy to manage the power delivery across varied terrains. The liquid-cooled design, paired with a Mikuni BST 40 carburettor, not only enhances performance but also ensures optimal thermal efficiency, making the bike reliable even during extended rides. This combination of power and precision translates to a thrilling experience, whether you’re ripping through a canyon or cruising through city streets. The 2006 KTM 450 SMR is loaded with features that enhance both performance and comfort. The double-ground, chrome-moly-steel frame is powder-coated for durability, providing a lightweight yet sturdy foundation that allows for agile maneuverability. The WP-USD front suspension and WP-PDS rear shock absorber offer impressive travel—300 mm at the front and 335 mm at the rear—ensuring a smooth ride over bumps and obstacles. Stopping power is assured with its single disc brakes, featuring a 310 mm diameter at the front and a 220 mm diameter at the rear, giving riders confidence in their ability to control speed. The bike's ground clearance of 310 mm further enhances its off-road capabilities while still maintaining an accessible seat height of 855 mm. **
Pros
- Powerful Engine Performance: The 449.4 cc engine delivers robust torque and responsive acceleration, making it thrilling to ride.
- Versatile Design: Ideal for both urban and off-road adventures, thanks to its lightweight frame and agile handling.
- Advanced Suspension System: With considerable travel in both front and rear suspension, riders enjoy exceptional comfort and control on various terrains.
Cons
- Kick Starter Only: The absence of an electric start can be inconvenient for some riders, especially in challenging conditions.
- Limited Fuel Capacity: With a 7-liter fuel tank, longer rides may require more frequent refueling.
- Height Consideration: The seat height may pose a challenge for shorter riders, impacting overall comfort and confidence when stopping.
Technical details
Source specification data
- Make
- KTM
- Model
- 450 SMR
- Category
- Super motard
- Starter
- Kick
- Clutch
- Multi-disc wet clutch, hydraulically operated
- Torque
- 42.50 Nm (4.3 kgf-m or 31.3 ft.lbs) @ 3250 RPM
- Gearbox
- 6-speed
- Ignition
- Kokusan digital 4K-3A
- Fuel System
- Carburettor. Mikuni BST 40
- Bore X Stroke
- 95.0 x 63.4 mm (3.7 x 2.5 inches)
- Compression
- 12.0:1
- Displacement
- 449.40 ccm (27.42 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Exhaust System
- Aluminum
- Lubrication System
- Pressure lubrication with 2 oil pumps
- Transmission Type Final Drive
- Chain
- Dry Weight
- 108.5 kg (239.2 pounds)
- Seat Height
- 855 mm (33.7 inches) If adjustable, lowest setting.
- Fuel Capacity
- 7.00 litres (1.85 gallons)
- Overall Width
- 450 mm (17.7 inches)
- Ground Clearance
- 310 mm (12.2 inches)
- Rake
- 26.5°
- Trail
- 90 mm (3.5 inches)
- Rear Tyre
- 165/55-17
- Frame Type
- Double ground, chrome-moly-steel frame, powder-coated
- Front Tyre
- 120/75-17
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- WP-PDS shock absorber
- Front Suspension
- WP-USD 48 mm (1.89 inches)
- Rear Wheel Travel
- 335 mm (13.2 inches)
- Front Wheel Travel
- 300 mm (11.8 inches)
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 310 mm (12.2 inches)
