KTM 450 SMR
2009Super Moto

KTM 450 SMR

Key specifications

Engine
449 cc
Weight
112 kg
Fuel type
petrol
Fuel capacity
2.2 L
Transmission
5-speed
Seat height
36 mm
Front brakes
Single disc. Magura four piston, radially bolted caliper
Rear brakes
Single disc. Brembo single-piston, floating caliper

Overview

Introducing the 2009 KTM 450 SMR, a machine that embodies the spirit of super motard racing while delivering exhilarating performance on both the track and the street. KTM has carved a niche for itself in the motorcycle market with its bold designs and uncompromising engineering, and the 450 SMR is no exception. This lightweight powerhouse is designed for riders who crave agility, speed, and versatility in their rides. With a potent single-cylinder engine and a race-ready chassis, the SMR stands as a testament to KTM's commitment to performance-driven motorcycles. At the heart of the 2009 450 SMR lies a robust 449.30 cc single-cylinder, four-stroke engine that produces an exhilarating burst of power, thanks to its high compression ratio of 12.5:1. The engine's design features a bore and stroke of 97.0 x 60.8 mm, ensuring that it delivers both torque and horsepower in a thrilling combination. The Keihin MX FCR 41 carburettor fuels this beast, while the Kokusan ignition ensures crisp throttle response and reliable starts. With a 5-speed gearbox and an APTC antihopping hydraulic clutch, riders can seamlessly shift through the gears, making the most of the bike's agile handling and impressive acceleration. The liquid cooling system keeps the engine temperature in check, allowing for spirited rides without the worry of overheating. The 450 SMR is not just about raw power; it also boasts an advanced chassis and suspension system that enhances its riding characteristics. The chromium-molybdenum double-cradle frame, paired with an aluminum subframe, provides an incredible rigidity-to-weight ratio, ensuring stability at high speeds and during cornering. The WP USD front suspension offers 280 mm of travel, while the rear PDS mono shock provides 310 mm, allowing the bike to absorb bumps and provide a smooth ride on a variety of surfaces. Coupled with impressive braking components, including a 310 mm front disc with a Magura four-piston caliper and a 220 mm rear disc, the 450 SMR delivers confidence-inspiring stopping power. And let's not forget its striking orange color, which is sure to turn heads wherever you ride. **

Pros

  • Lightweight and Agile: Weighing in at just 111.5 kg (245.8 pounds), the 450 SMR offers incredible maneuverability, making it a joy to ride on twisty roads and tight tracks.
  • Powerful Engine: The single-cylinder engine packs a punch, offering robust torque and horsepower for thrilling acceleration.
  • Advanced Suspension: With 280 mm of front travel and 310 mm at the rear, the suspension setup smooths out rough terrain and enhances handling, ensuring a comfortable ride.

Cons

  • Seat Height: At 920 mm (36.2 inches), the seat height may be a challenge for shorter riders, making it less accessible for everyone.
  • Fuel Capacity: With an 8.20-liter (2.17-gallon) tank, the fuel capacity may limit long-distance rides without frequent stops for refueling.
  • Limited Storage: As a pure super motard, the 450 SMR lacks storage options, making it less practical for everyday commuting compared to more touring-oriented motorcycles.

Technical details

Source specification data

Make
KTM
Model
450 SMR
Category
Super motard
Starter
Electric
Color Options
Orange
Clutch
APTC Antihopping, operated hydraulically
Gearbox
5-speed
Ignition
Kokusan
Fuel System
Carburettor. Keihin MX FCR 41
Bore X Stroke
97.0 x 60.8 mm (3.8 x 2.4 inches)
Compression
12.5:1
Displacement
449.30 ccm (27.42 cubic inches)
Cooling System
Liquid
Engine Details
Single cylinder, four-stroke
Lubrication System
Pressure lubrication
Valves Per Cylinder
4
Transmission Type Final Drive
Chain
Dry Weight
111.5 kg (245.8 pounds)
Seat Height
920 mm (36.2 inches) If adjustable, lowest setting.
Fuel Capacity
8.20 litres (2.17 gallons)
Ground Clearance
300 mm (11.8 inches)
Rake
26.5°
Trail
119 mm (4.7 inches)
Rear Tyre
170/55-R17
Frame Type
Chromium
-
Molybdenum
central double-cradle-type frame, powder coated.
Aluminium
subframe.
Front Tyre
125/80-R20
Rear Brakes
Single
disc.
Brembo
single-piston, floating caliper
Front Brakes
Single
disc.
Magura
four piston, radially bolted caliper
Rear Suspension
WP PDS mono shock
Front Suspension
WP USD
Rear Wheel Travel
310 mm (12.2 inches)
Front Wheel Travel
280 mm (11.0 inches)
Rear Brakes Diameter
220 mm (8.7 inches)
Front Brakes Diameter
310 mm (12.2 inches)

Available colors

Orange
